AMPLIFIER SECTION

INPUT SECTION

CROSSOVER SECTION

SYSTEM SPECIFICATIONS

7060B

7070A

7071A

Free field frequency response

19 Hz…85 Hz

19 Hz…85 Hz

19 Hz…85 Hz

(+/- 3 dB)

LFE 85/120 Hz

LFE 85/120 Hz

LFE 85/120 Hz

Maximum short term sine wave

SPL output averaged from

30 to 85 Hz, measured in

half space at 1 meter

≥ 108 dB SPL

≥ 112 dB SPL

≥ 118 dB SPL

Maximum peak SPL output with

random pink noise, measured

in half space at 1 meter

≥ 113 dB SPL

≥ 117 dB SPL

≥ 123 dB SPL

Self generated noise level in

free field @ 1 m on axis

(A-weighted)

≤ 15 dB

Harmonic distortion

@ 90 dB SPL

@ 95 dB SPL

@ 100 dB SPL

at @ 1 m on axis in half space 30 … 85 Hz

30 … 85 Hz

30 … 85 Hz

2nd

≤ 3 %

≤ 3 %

≤ 3 %

3rd

≤ 2 %

≤ 3 %

≤ 3 %

Driver, magnetically shielded

250 mm (10”)

305 mm (12”)

2 x 305 mm (12”)

Weight

26 kg (57 lbs)

50 kg (110 lbs)

81 kg (178 lbs)

Dimensions

Height

527 mm (20 3/4”)

625 mm (24 5/8”)

755 mm (29 3/4”)

Width

462 mm (18 3/16”)

555 mm (21 7/8”)

803 mm (31 5/8”)

Depth

363 mm (14 5/16”)

490 mm (19 5/16”)

490 mm (19 5/16”)

7060B

7070A

7071A

Short term amplifier output

power (Long term output power

is limited by driver unit

protection circuitry)

120 W

250 W

500 W

Amplifier system distortion

at nominal output

THD

≤ 0.05%

Mains voltage

230 V, 115/230V or 100/200V

according to region

Power consumption (average)

Idle

15 VA

15 VA

30 VA

Full output

150 VA

250 VA

500 VA

OUTPUT SECTION

CONTROLS

7060B

7070A

7071A

Input connector XLR female

pin 1

gnd

pin 2

+

pin 3

Input impedance

10 kOhm balanced

Input level for 100 dB SPL

output @ 1 m

Variable from +12 to –6 dBu

7060B

7070A

7071A

Output connector XLR male

pin 1

gnd

pin 2

+

pin 3

Remote LED connector (RJ11)

Remote LED for Power/Overload+Bypass and LFE +10 dB

Main monitor Out gain

0 dB

Sum Out gain

0 dB

7060B

7070A

7071A

Input sensitivity

+12 to –6 dBu for 100 dB @ 1 m

Bypass

Bypasses the bass management for the main channels

LFE bandwidth

85 / 120 Hz

LFE sensitivity

0 / +10 dB

Redirect

Redirects LFE channel signal above 85 Hz to center channel

Sum in

Changes subwoofer to Sum in mode

Test tone for phase adjustment

85 Hz

Bass Roll-Off

0/-2 dB/ -4 dB/ -6 dB 0/-2 dB/ -4 dB/ -6 dB 0/-2 dB/ -4 dB/ -6

@ 20 Hz

@ 20 Hz

dB @ 20 Hz

Phase

0/90/180/270° @ 85 Hz

7060B

7070A

7071A

Subsonic filter

(18 dB/octave) below

19 Hz

19 Hz

19 Hz

Crossover frequency,

(sub/main channels)

85 Hz

LFE cutoff Hz

85 Hz/120 Hz selectable

Crossover slopes

Lowpass

36 dB/octave

Highpass

12 dB/octave

Midband rejection >400 Hz

≥ 50 dB

Bass Roll-Off control operating From 0 to –6 dB

From 0 to –6 dB

From 0 to –6 dB

range in 2 dB steps

@ 20 Hz

@ 20 Hz

@ 20 Hz

Phase matching control

From 0 to 270

in 90° steps

@ 85 Hz

7060B, 7070A and 7071A Operating Manual
