Side discharge, Sq side discharge bsq side discharge, Figure 5 figure 4 – Greenheck Fan Greenheck Centrifugal Inline Fans SQ/BSQ User Manual
Page 11
11
SQ Side Discharge Duct Openings
Unit Size
Width
Height
60-75
9
7
⁄
8
(251)
8
7
⁄
8
(225)
80-95
12
7
⁄
8
(327)
11
7
⁄
8
(302)
100
13
7
⁄
8
(352)
13
7
⁄
8
(352)
120
15
7
⁄
8
(403)
15
7
⁄
8
(403)
130
17
7
⁄
8
(454)
17
7
⁄
8
(454)
140
19
7
⁄
8
(505)
19
7
⁄
8
(505)
160
22
7
⁄
8
(581)
22
7
⁄
8
(581)
All dimensions in inches (millimeters).
Left Side
Discharge
Right Side
Discharge
Inline
Discharge
Inlet
Height
Width
Height
Left Side
Discharge
Right Side
Discharge
Inline
Discharge
Inlet
Width
Figure 5
Figure 4
BSQ Side Discharge Duct Openings
Unit Size
Width
Height
70-80-90
11
7
⁄
8
(302)
11
7
⁄
8
(302)
100
13
7
⁄
8
(352)
13
7
⁄
8
(352)
120
15
7
⁄
8
(403)
15
7
⁄
8
(403)
130-130HP
17
7
⁄
8
(454)
17
7
⁄
8
(454)
140-140HP
19
7
⁄
8
(505)
19
7
⁄
8
(505)
160-160HP
22
7
⁄
8
(581)
22
7
⁄
8
(581)
180-180HP
23
7
⁄
8
(606)
23
7
⁄
8
(606)
200-200HP
27
7
⁄
8
(708)
27
7
⁄
8
(708)
240-240HP
28
7
⁄
8
(733)
34
7
⁄
8
(886)
300-300HP
31
7
⁄
8
(810)
41
7
⁄
8
(1064)
360-360HP
32
7
⁄
8
(835)
37
7
⁄
8
(962)
420
34
7
⁄
8
(886)
43
7
⁄
8
(1114)
All dimensions in inches (millimeters).
SQ Side Discharge
BSQ Side Discharge
Side Discharge
Access Door
Access Door
