Section 1 — General Information
Guardian Air-cooled 7 kW, 12 kW and 15 kW Generators
1.4 THE
GENERATOR
Control Panel
Battery Compartment
Fuel Inlet
Air Filter
Exhaust
Enclosure
Oil Filter
Data Decal
Fuel Regulator
Oil Check/Fill
Control
Panel
Air Filter
Exhaust
Enclosure
Battery Compartment
Fuel Inlet
Oil Filter
Oil Dipstick
Data
Decal
Fuel Regulator
Figure 1.2 – 12 kW/15 kW, V-twin GT-990 Engine
Figure 1.1 – 7 kW, Single Cylinder GH-410 Engine
Generac® Power Systems, Inc.
5
