-12- H3124 Banjo Kit
To install the tuning machines:
1. Slide the tuning machines through the back
of the headstock.
2. Place the washer and barrel nut over the tun-
ing post and tighten with a 10mm socket.
Figure 13. Tuning machines installed in the
back of the headstock
To install the tailpiece:
1. Insert the tailpiece screw through the tail-
piece lug.
2. Set the tailpiece on the tensioning hoop, as
shown in
Figure 14, and tighten the nut
against the tailpiece lug.
Figure 14. Tightening tailpiece screw into lug.
Tailpiece
Tailpiece
Tailpiece Lug
Tuning Machines
