COMPONENTS INCLUDED IN 0G2283D
1 0F1823A 1
ENCL
HSB
CONTROL
PANEL
2 0F3078 1
COVER
CONTROL
PANEL
3 0F2606 1
HINGE
CONTINUOUS
H-PANEL
4
036261
6
RIVET POP .125 X .275 SS
5
0E7358
4
SCREW PPPH HI-LO #4-24 X 3/8
6
052777
3
WASHER FLAT M3
7
0G1303C
1
ASSY PCB R-200 1800 RPM 2.4L
8 0F1262 4
HOLDER
FUSE
WICKMANN
178.6150
9
0F1263
1
ADPTR RH SIDE WICKMAN 178.6191
10
0F1264
1
ADPTR LH SIDE WICKMAN 178.6192
11
0F1725C
1
ASSY PCB 2AMP 12V UL BATT CHGR
12 067680 1
ASSY
VOLTAGE
REGULATOR
60HZ
13
0E6875A
2
RELAY 12VDC C FORM W/DIODE
14
055911
1
BLOCK TERM 20A 12 X 6 X 1100V
15
0F5459
1
DECAL CPL CONTROL PANEL FUSES
16
0E3161
1
ASSY PCB BOSCH GOV DRIVER
18 0F5462 1
DECAL
CPL
3.9L
TB1
19
0A5062J
4
SPACER 9.5H 3.2 ID
20
029673
1
DIO BRIDGE 25A 600V
21
048467
1
CIRCT BRK 7 X 1 ETA 46-500-P
22
0F1958
1
PLATE HARNESS CLAMP
23
082573
1
SWITCH RKR DPST 125V SPD
24
0E4494
1
SWITCH RKR DPDT ON-OFF-ON
25 0F3215 1
DECAL,
CONTROL
HSB
26
0F6305
2
SEAL COVER 3.18 X 12.7 X 382
27
0F6305A
1
SEAL COVER 3.18 X 12.7 X 283
28
0F5886
3
SCREW HHPM M5-0.8 X 12
29
051713
12
WASHER FLAT M5
30 049226 12
WASHER
LOCK
M5
31
0F5752F
1
RES WW 15R 5% 25W QK CONN
32
0F5884
2
SCREW PHTT M3.5-0.6 X 10
33
0F5896
2
SCREW PHTT M3.5-0.6 X 16
34
0C2265
4
SCREW PHTT M4-0.7 X 12 ZYC
35
0C3990
2
SCREW PHTT M4-0.7 X 10 ZYC
36
091526
4
SCREW PPHM M5-0.8 X 12 ZNC
37
051716
9
NUT HEX M5-0.8 G8 CLEAR ZINC
38
079224
2
SCREW PPHM M5-0.8 X 30 SS
43 043182 7
WASHER
LOCK
M3
44
051714
7
NUT HEX M3-0.5 G8 YEL CHR
45
0F3192
1
SUPPORT ANGLE PCB
46
0E7403C
1
FUSE ATO TYPE 15 AMP (BLUE)
47
0G2281
1
HARN R-200 CTRL PNL 1800 RPM (NOT SHOWN)
COMPONENTS INSTALLED PER THIS DRAWING
A
056739
1
RELAY SOLENOID 12VDC PNL MNT
B
022287
2
SCREW HHC 1/4-20 X 3/4 G5
C
022473
4
WASHER FLAT 1/4-M6 ZINC
D 022097 2
WASHER
LOCK
M6-1/4
E
022127
2
NUT HEX 1/4-20 STEEL
F
0F6145
A/R
SEAL WEATHER .45"DIA
G
0F2627A
1
COVER CONTROL PANEL SIDE
H
091526
4
SCREW PPHM M5-0.8 X 12 ZNC
J 049226 4
WASHER
LOCK
M5
K
051713
4
WASHER FLAT M5
