Specifications
Dimensions:
Mid/Tweeter Wing:
H 75” x W 21” x D 16”
Woofer Tower:
H 75” x W 15” x D 26”
Amplifier (stack):
H 11” x W 17” x D13”
Power Supply:
H 6” x W 10” x D 12”
Weight:
720
lbs
(328kg)
wing/towers
90
lbs
(41kg)
amplifier
total
Frequency Response:
16Hz to 36kHz, +/- 2dB
Controls (on amplifier):
Bass volume, phase,
low-pass,
high-pass
Controls (on speaker):
Rear Tweeters (+/- 1 dB)
Midrange
(+/-
0.75
dB)
Input Impedance:
4 ohms (nominal)
33K
ohms
(amplifier)
Sensitivity:
91 dB 1 watt 1 meter
Amplifier Power Rating:
4 channels @500 watts each
Power Supply 1kVA per side
Amplifier
Inputs:
1pair
XLR
(balanced)
Finish:
Acrylic
composite
