5
KEY BUTTON
Power/Mute Power (Long Push >= 2sec): Turn on the device, press it
again to close any open windows and turn it off (enter a
standby mode)
Mute
Mute(Short Push < 2sec ) : Press Menu button to go back to
System menu
Reset Use the stylus tip to press down the reset button through the
hole to reset the system.
Volume UP Volume up
Volume Down Volume down
Battery Slide Switch (ON/OFF switch) Slide to “OFF” to disable battery power
supply to the system.
Menu Press Menu button to go back to System menu
Mechanical
Dimension 150mm(L) x90.5mm(W) x 24.2mm(H)
Main Unit Weight 288g
DVBT Unit Weight 121g
Temperature
Operating 0°C ~ 50°C
Storage -20°C ~ 70°C
Humidity Operational up to 95% non-condensing
Safety & EMI
FCC Approved, CE marked, BQB Approved
Bluetooth
Chip CSR, BC03 multimedia
Profile Support: Headset / Handsfree / A2DP / AVRCP / OPP
Sensitivity -80 dBm @0.1% BER
Accessory
Car charger 5V / 2A
Travel charger 5V / 2A
DVBT IR remote 26 Key, Name Card Type
DVBT antenna X 2,
DVBT
Tuner Built-in Dual Tuner for diversity
Channel Frequency UHF / VHF (470~862 MHz / 174~230 MHz)
Channel Band Width 6 / 7 / 8 MHz
Demodulation COFDM with 2K / 8K FFT
Receive Sensitivity -85 dBm(16QAM)
IR Remote Control 26 Key
