Grizzly 3/4 Hp electric motor G2904 - Manual (Page 2)

-2-
g2904 3 ⁄
4
hp electric Motor (Mfg. since 04/06)
g2904 Wiring diagram
View this page in color at
www.grizzly.com.
Start
Capacitor
200 MFD
125 VAC
110V
Bl
Bl
(PREWIRED)
Ground 6
Bl
Bl
5
Start
Capacitor
200 MFD
125 VAC
Bl
Bl
6
Bl
5
Bl
Ground
COLOR KEY
BLACK
RED
WHITE
YELLOW
GREEN
BLUE Bl
220V
CLOCKWISE
220V
COUNTERCLOCKWISE
To reverse motor direction,
switch wires #5 & #6.
110V MOTOR DIRECTION
Ground
Bl
5
6
Bl
The motor wiring shown here is
current at the time of printing, but it
may not match your machine.
Always use the wiring diagram
inside the motor junction box.
