Grindmaster PIC-4 - Manual (Page 2)

PIC-4 Series - Four Flavor
Powdered Specialty Beverage Dispenser with Focus Flavor Hopper
Specifications Model PIC-4
Electrical & Listings
PIC-4: 120V/60Hz / 1650W / 14A (UL/ NSF)
PIC4-CUL: 120V/60Hz / 1400W / 12A (CUL, UL, NSF)
# of Hoppers 4
Hopper Size
(3) 5.5 lb (2.5 kg)
(1) 11.5 lb (5.2 kg)
Water Line Connection 1/4” (6.35 mm) flare
Tank Size 3.5 Gallons (13.2 liters)
Cup Clearance 7” (18 cm) standard
Dimensions (H x W x D)
32-1/2”* x 16-1/2” x 22” (83 cm x 42 cm x 57 cm)
*Add 4” to 5” (10.2 cm - 12.7 cm) to height when using 4” adjustable legs
Ship Dimensions (H x W x D) 38” x 21” x 27” (97 cm x 53 cm x 69 cm)
Weight 80 lbs (37 kg)
Ship Weight 100 lbs (46 kg)
Model PIC-4W
Grindmaster® Coffee Grinders and Brewers • PrecisionBrew™ Brewing Systems • Espressimo® Espresso Machines
Crathco® Hot Beverage Dispensers • Crathco® Cold and Frozen Beverage Dispensers • AMW Coffee and Tea Systems
Tel (502) 425-4776 • Fax (502) 425-4664 • 1-800-695-4500 (USA & Canada only)
P.O. Box 35020 • Louisville, KY 40232 • USA
www.grindmaster.com • email: [email protected] 0608 Form # CC-262-05 © Grindmaster Corporation, 2002
PRINTED IN USA
• Manual Flow*
• Single Portion per head*
* Available with or without hot water option
• Three portion sizes per head plus “top-off”
Choice of Controls:
5.5 lb hoppers
11.5 lb Focus
Flavor hopper
optional hot water dispense
Specifications are subject to improvement or change without notice.
Standard Options* (standard unit has manual flow dispensing)
Water Pump (Part # 60568) (115V / 60Hz) External water pump allows standard machine to operate off of remote or bottled water supply.
Soluble Coffee Option
Serve fresh, hot coffee fast using your soluble coffee with our soluble coffee option. Available on
1 to 4 dispense heads (specify number of heads).
* Additional cost applies
Custom Options* (available with minimum purchase quantity)
Hot Water Dispense - add “W” to end of model # Fifth dispense head at center of unit for hot water
Portion Control - 3 cup sizes & top off
(add “3A” to model #) Dispenses preset portion of product at the push of a button - 3 cup sizes (small, medium, large)
per head plus top off button are easily programmed
Key Lock Lock on door offers added security (additional cost applies)
High Capacity Output (add “Q” to model number) 2500W heater offers extra quick recovery for added capacity (120/240V / 2500W / 60Hz).
