Part list/exploded drawing, Adjustment – Gold's Gym GGMC04930 User Manual
Page 3
2
1
2
PART LIST/EXPLODED DRAWING—
R0803A
Model No. GGMC04930
3
1
1
Lat Bar
2
2
Handgrip
#
1
User’s Manual
Note: “#” indicates a non-illustrated part.
Specifications are subject to change without notice.
Key No. Qty.
Description
ADJUSTMENT
ATTACHING THE LAT BAR
The Lat Bar (1) can be attached to the medium nylon
ropes (A) with two cable clips (B).
1
A
A
B
B
