HTS6
Subsonic filter
(18 dB/octave) below 19 Hz
Upper bandwidth 120 Hz
Crossover slopes
Lowpass 36 dB/octave
Highpass 12 dB/octave
Midband rejection >400 Hz 50 dB
Bass roll-off control operating From 0 to –6 dB @ 20 Hz
range in 2 dB steps
Phase matching control From 0 to 270° @ 85 Hz
in 90° steps
AMPLIFIER SECTION
INPUT SECTION
CROSSOVER SECTION
SYSTEM SPECIFICATIONS
HTS6
Free field frequency response 19 Hz…120 Hz
(+/- 3 dB)
Maximum short term sine wave
SPL output averaged from
30 to 85 Hz, measured in
half space at 1 meter 124 dB SPL
Maximum peak SPL output with
random pink noise, measured
in half space at 1 meter 129 dB SPL
Self generated noise level in
free field @ 1 m on axis
(A-weighted) 20 dB
Harmonic distortion @ 105 dB SPL
at @ 1 m on axis in half space 30 … 85 Hz
2nd 2 %
3rd 2 %
Drivers 4 x 305 mm (12”)
Weight 120 kg (265 lbs)
Dimensions
Height 524 mm (20 5/8”)
Width 1440 mm (56 11/16”)*
Depth 558 mm (22”)
* If the subwoofer is flush mounted into a wall or a cabinet, the recess must be 20 cm (8”)
wider than the subwoofer to allow sufficient clearance for the reflex port situated at the end
of the subwoofer enclosure.
HTS6
Short term amplifier output
power (Long term output power
is limited by driver unit
protection circuitry) 1000 W
Amplifier system distortion
at nominal output
THD 0.05%
Mains voltage 100/200V
or 115/230V
Power consumption (average)
Idle 60 VA
Full output 1000 VA
LINK OUT CONNECTOR
HTS6
Input connector XLR female
pin 1 gnd
pin 2 +
pin 3 –
Input impedance 10 kOhm balanced
Input level for 100 dB SPL
output @ 1 m Variable from +6 to –12 dBu
HTS6
Output connector XLR male
pin 1 gnd
pin 2 +
pin 3 –
Link Out gain 0 dB
