EC Declaration of Conformity
This is to certify that the Genelec AOW312B Active On-Wall
Loudspeaker conforms to the following standards:
Safety:
EN / IEC 60065:1998 6th Edition
EMC:
EN 55020 : 2002 + A1 : 2003
EN 55013: (2001)
EN 61000-3-2 (2000)
EN 61000-3-3 (1995)
The product herewith complies with the requirements of
The Low Voltage Directive 73/23/EEC, EMC Directive
89/336/EEC and 93/68/EEC
Signed:
Ilpo Martikainen
Position: Chairman of the Board
Date: 12-May-2008
3. This loudspeaker is capable of
producing sound pressure levels in
excess of 85 dB, which may cause
permanent hearing damage.
4. A free flow of air through the amplifier is
necessary to maintain sufficient cooling.
Do not obstruct airflow through the
amplifier
5. To prevent fire or electric shock, do not
expose the unit to water or moisture. Do
not place any objects filled with liquid,
such as vases on or near the
loudspeaker or the amplifier.
6. Note that the amplifier is not completely
disconnected from the AC mains service
unless mains plug or appliance coupler
of the amplifier is disconnected
from the mains outlet. Ensure that the
plug or appliance coupler of the
amplifier is readily operable and easily
accessible for doing this.
Guarantee
This product is supplied with a two year guar-
antee against manufacturing faults or defects
that might alter its performance. Refer to sup-
plier for full sales and guarantee terms.
Figure 8: The curves above show the effect of the ‘bass’, ‘mid’ and
‘treble’ level controls, and the ‘bass tilt’ and ‘bass roll-off’ controls
on the free field response of the AOW312B, measured at 2 m.
AUDIO PRECISION AOW312 ANEC vs 04 AUG 06
80
85
90
80
85
90
80
85
90
LEVEL(dBr)
20 100 1k 10k 20k
FREQ(Hz)
BASS TILT
BASS LEVEL TREBLE LEVEL
BASS ROLL-OFF MIDRANGE LEVEL
AUDIO PRECISION AOW312 ANEC vs 04 AUG 06
60
65
70
75
80
80
85
85
90
90
95
95
100
100
LEVEL(dBr)
20 100 1k 10k 20k
FREQ(Hz)
0
15
30
45
Figure 9: The upper curve group shows the horizontal directivity
characteristics of the AOW312B in its vertical configuration
measured at 2 m. The lower curve is a 1/6 octave power
response measurement, derived from 144 individual directivity
measurements.
