ITEM PART DESCRIPTION QTY.
1 07600 Crankcase 1
2 13000 Oil Filler Plug Assembly 1
4 07601 Crankcase Cover 1
5 07602 Gasket, Crankcase Cover 1
8 07603 Oil Dip Stick 1
9 01009 O-Ring, Dip Stick 1
10 13133 Hexagon Screw 12
11 13134 Spring Washer 12
12 07109 Drain Plug 3
13 07182 Gasket, Drain Plug 2
14 07607 Bearing Cover 2
15 07608 Radial Shaft Seal 2
16 07184 O-Ring 2
20 07610 Taper Roller Bearing 2
20A 07611 Fitting Disc (Shim) 1-5
21 07612 Shaft Protector 1
22 13405 Crankshaft 1
23 07614 Key 1
24 13182 Connecting Rod Assy. 3
25 13183 Crosshead Assy. 3
28 13184 Crosshead Pin 3
30 07619 Cover Plate 1
30A 07225-0100 Hexagon Screw 8
30B 13136 Grommet 4
30C 08280 Washer 8
30D 13154 Cover Plate 1
31 07623 Eye Bolt 1
32 07624 Radial Shaft Seal 3
32A 07625 Shaft Seal 3
33 07626 Seal Retainer 3
33A 07627 O-Ring 3
33B 07628 Circlip 3
33C 07249 Fitting Disc 3
34 13137 Oil Scraper 3
36 07706 Plunger Pipe Assy.
(GP7155A/GP7255A) (36 A-D)
3
36 07630 Plunger Pipe Assy. (36A-D) 3
36A 07667 Plunger Connection 3
36B 07793 Plunger Pipe (50mm) 3
36B 07666 Plunger Pipe (55mm)
(GP7155A/GP7255A)
3
36C 07664 Tension Screw 3
36D 07665 Copper Ring 3
38 13155 Seal Case (GP7155A/GP7255A) 3
5
ITEM PART DESCRIPTION QTY.
38 07794 Seal Case (GP7150A) 3
38A 13156 O-Ring 3
38B 07721 O-Ring (GP7155A/GP7255A) 3
38B 06258 O-Ring (GP7150A) 3
38C 07635 Support Ring (GP7150A Only) 3
39 13157 Seal Sleeve (GP7155A/GP7255A) 3
39 07795 Seal Sleeve (GP7150A) 3
39A 07723 Compact Ring (GP7155A/GP7255A) 3
39A 07796 Compact Ring (GP7150A) 3
40* 07797 Support Disc (GP7155A/GP7255A) 3
41 13158 O-Ring (GP7155A/GP7255A) 3
41 07636 Tension Spring (GP7150A) 3
42 07711 V-Sleeve (GP7155A/GP7255A) 6
42 07638 V-Sleeve (GP7150A) 6
43 07712 Pressure Ring (GP7155A/GP7255A) 3
43 07639 Pressure Ring (GP7150A) 3
44 07637 Support Ring (GP7150A only) 3
49 13159 Stud Bolt 8
49A 13160 Hex Nut 8
50 07790 Valve Casing (GP7155A) 1
50 07791 Valve Casing (GP7255A) 1
50 06628 Valve Casing (GP7150A) 1
50A 13162 Cylinder Stud 2
51 08288 Valve Assembly 6
51A 08281 Spring Tension Cap 6
51B 08282 Valve Spring Guide 6
51C 07732-0100 Valve Spring 6
51D 13164 Valve Plate 6
51E 08283 Valve Seat 6
51F 07653 O-Ring 6
51G 13166 Support Ring 6
51H 07266 O-Ring 6
56 13167 Valve Adaptor 3
56A 07658 O-Ring 6
56B 07635 Support Ring 6
56C 13166 Support Ring 3
56D 07653 O-Ring 3
57 13173 Tension Spring 6
58 13170 Plug 3
59A 07661 Copper Ring 1
60 12251 Plug, 1-1/4” NPT 1
61 12252 Plug, 2-1/2” NPT 1
66 13362 Disc For Crankshaft 1
67 13358 Hexagon Screw 1
* This item may be removed to add a third v-sleeve.
Plunger Packing Kit
# 09526 - GP7150A
Item
Part # Description Qty.
38A 13156 O-Ring 3
38B 06258 O-Ring 3
39A 07796 Compact Ring 3
41 07636 O-Ring 3
42 07638 V-Sleeve 6
Plunger Packing Kit
# 9220 - GP7155A & GP7255A
Item
Part # Description Qty.
38A 13156 O-Ring 3
38B 07721 O-Ring 3
39A 07223 Compact Ring 3
41 13158 O-Ring 3
42 07711 V-Sleeve 6
Oil Seal Kit - # 09221
Item Part # Description Qty.
32 07624 Radial Shaft Seal 3
32A 07625 Shaft Seal 3
33A 07627 O-Ring 3
Spare Parts List - GP7150A/GP7155A/GP7255A
Valve Kit
# 09606*
Item Part # Description Qty.
51B 08282 Valve Spring Guide 1
51C 07732-0100 Valve Spring 1
51D 13164 Valve Plate 1
51E 08283 Valve Seat 1
51F 07653 O-Ring 2
51G 13166 Support Ring 2
51H 07266 O-Ring 2
56A 07658 O-Ring 2
56B 07635 Support Ring 2
56C 13166 Support Ring 1
56D 07653 O-Ring 1
* Note: When ordering a valve kit for a pump produced
prior to 11/03, order kit #09222, which replaces part
08281 with p/n 13163. Kit 09222 does not require p/n
08282.
