11
GB
1. Screw telescopic pipe
ቢ on the pump.
2. Release clamping sleeve
ባ of the telescopic pipe.
3. Adjust telescopic pipe stalk
ቤ to the height of
the container. The length of the telescopic pipe
can be adjusted between 39 – 62 cm.
4. Tighten clamping sleeve
ባ by hand.
The length of the telescopic pipe
ቤ should be set
in such a way that the pump does not touch the
bottom of the container. This prevents dirt in the
container reaching the pump.
A rope must be run through the handle
ብ of the
pump for deeper water containers (max. 1.5 m).
ቢ
ባ
ቤ
If the battery pump is used in flat containers, e.g. to empty a
paddling pool, the telescopic pipe can be removed and replaced
by the threaded tap connector supplied. The 13 mm (1/2”),
16 mm (5/8”) or 19 mm (3/4”) hose connection must be set up
using Original GARDENA System hose connections.
Setting up the telescopic
pipe on the container:
Complete Solution:
(a) the GARDENA Rain Water
Collection Filter (Art. No.
3820 / 3821)
(b) the GARDENA Connecting
Set (Art. No. 3815),
(c) the GARDENA Rain Water
Tank (Art. No. 3801 / 3805)
(d) the matching GARDENA
Cover for Rain Water Tank
(Art. No. 3800 / 3804), and
(e) the GARDENA Battery Pump
(Art. No. 1498).
Use in shallow vessels:
ብ
4. Operating
Charging the battery: The battery may only be charged using the NL-12 charger
supplied or the solar panel, Art. 7851-00.620.00 with charging
cable Art. 1498-20.600.22, obtainable from GARDENA Service.
Operating the pump is not possible during charging !
The battery is partially charged in the works for safety reasons.
The battery must be charged before it is used for the first time.
As this NiCd-battery is subject to self-discharging, the battery
must be charged up to reach a full charge if it has been stored for
a relatively long time.
Art. No. 3820/21
Art. No. 3815
Art. No. 380 1/3805
Art. No. 380 0/3804
Art. No. 1498
