Goodman Mfg CPC048XXX4BXXXBA - Manual (Page 7)

Cabinet Assy
Ref.
No: Part
No:
Description:
Ref.
No: Part
No:
Description:
Image 1:
INSULATED ASSY, FILTER DOOR (M1, M2, M3,
M4, M5, M6, M7, M8, M9, M10, M11, M12, M13,
M14, M15, M16) 0270L00080 11
INSULATED ASSY, FILTER DOOR (M17, M18,
M19, M20, M21, M22) 0270L00139 11
INSULATED ASSY, ECONOMIZER DOOR 0270L00081 21
POST-SIDE SUPPORT (M1, M2, M3, M4, M5, M6,
M7, M8, M9, M10, M11, M12, M13, M14, M15, M16) 0121L00233RFDG 31
POST-SIDE SUPPORT (M17, M18, M19, M20, M21,
M22) 0121L00343RFDG 31
CORNER POST (M1, M2, M3, M4, M5, M6, M7, M8,
M9, M10, M11, M12, M13, M14, M15, M16) 0121L00237RFDG 41
CORNER POST (M17, M18, M19, M20, M21, M22) 0121L00344RFDG 41
LOUVERED COMPRESSOR PANEL (M1, M2, M3,
M4, M5, M6, M7, M8, M9, M10, M11, M12, M13,
M14, M15, M16) 0121L00263DG 51
LOUVERED COMPRESSOR PANEL (M17, M18,
M19, M20, M21, M22) 0121L00354DG 51
SMOKE DETECTOR COVER 0121L00321 NS
Image 2:
INSULATED ASSY, DUCT PANEL (M1, M2, M3, M4,
M5, M6, M7, M8, M9, M10, M11, M12, M13, M14,
M15, M16) 0270L00079 12
INSULATED ASSY, DUCT PANEL (M17, M18, M19,
M20, M21, M22) 0270L00145 12
INSULATED ASSY, RETURN DUCT 0270L00011S 22
INSULATED ASSY, SUPPLY DUCT 0270L00012S 32
ELECTRIC HEAT DOOR 0121L00279DG 42
INSULATED ASSY, BLOWER DOOR (M1, M2, M3,
M4, M5, M6, M7, M8, M9, M10, M11, M12, M13,
M14, M15, M16) 0270L00084 52
INSULATED ASSY, BLOWER DOOR (M17, M18,
M19, M20, M21, M22) 0270L00146 52
RAIL CORNER BRACKET (QTY 4) 0121G00301 62
LOUVERED CONTROL PANEL (M1, M2, M3, M4,
M5, M6, M7, M8, M9, M10, M11, M12, M13, M14,
M15, M16) 0121L00262DG 72
LOUVERED CONTROL PANEL (M17, M18, M19,
M20, M21, M22) 0121L00353DG 72
Expanded Model Nomenclature
M1 - CPC036XXX3BXJXBA
M2 - CPC036XXX3BXXXBA
M3 - CPC036XXX4BXJXBA
M4 - CPC036XXX4BXXXBA
M5 - CPC048XXX3BXJXBA
M6 - CPC048XXX3BXXXBA
M7 - CPC048XXX4BXJXBA
M8 - CPC048XXX4BXXXBA
M9 - CPC048XXX7BXJXBA
M10 - CPC048XXX7BXXXBA
M11 - CPC060XXX3BXJXBA
M12 - CPC060XXX3BXXXBA
M13 - CPC060XXX4BXJXBA
M14 - CPC060XXX4BXXXBA
M15 - CPC060XXX7BXJXBA
M16 - CPC060XXX7BXXXBA
M17 - CPC072XXX3BXJXBA
M18 - CPC072XXX3BXXXBA
M19 - CPC072XXX4BXJXBA
M20 - CPC072XXX4BXXXBA
M21 - CPC072XXX7BXJXBA
M22 - CPC072XXX7BXXXBA
7 RP-480A www.goodmanmfg.com www.amana-hac.com
