Ordering information Technical specifications
Print technology HP Thermal Inkjet
Printhead nozzles 524
Print resolution Up to 2400 x 1200 optimised dpi from 1200 x 1200 dpi input on glossy media
Number of inks Black, cyan, magenta, yellow
Ink types Dye-based (C, M, Y), pigment-based (K)
Ink drop size 5 pl (C, M, Y), 15 pl (K)
Print speed Economic quality: 31.6 m²/hr (draft, coated, colour image), 25 sec/A1 page (draft, plain, colour line
drawing), 100 A1 prints per hour (draft, plain, colour line drawing). 3.3 min/page, A1 (coated), 3.9
min/page, A1 (glossy)
Line Line accuracy: +/- 0.1%. Minimum width: 0.02 mm
Print languages DJ4520 1067 mm: HP-GL/2, HP-RTL, TIFF, JPEG, CALS G4; DJ4520ps 1067 mm: Adobe® PostScript®
3, Adobe® PDF 1.5, TIFF, JPEG, HP-GL/2, HP-RTL, CALS G4
Memory Standard: 608 MB;
Maximum: 1120 MB;
Upgradability: Expandable to 1120 MB through a 512 MB Designjet qualified DIMM.
Hard disk: Standard, 160 GB.
Print margins (mm) Roll top: 5 mm; bottom: 5 mm; left: 5 mm; right: 5 mm
Sheet 5 mm (top), 5 mm (right), 5 mm (left), 5 mm (bottom)
Media types Bond and coated paper (bond, coated, heavyweight coated, super heavyweight plus matte), technical
paper (natural tracing, translucent bond, vellum), film (clear, matte, polyester), photographic paper
(satin, gloss, semi-gloss, matte, high-gloss), proofing paper (semi-gloss, semi-gloss contract),
self-adhesive (indoor paper, polypropylene, vinyl), banner and sign material (outdoor paper, blue back
billboard paper)
Media sizes Rolls up to 1067 mm width
Maximum media length Roll: 175 m
Maximum media width 1067 mm
Maximum print length 175 m (operating system and application dependent)
Media thickness Up to 0.4 mm
Recommended media weight 50 to 328 g/m²
Roll Maximum diameter: 180 mm
Media handling Two automatic roll feeds, automatic roll switching, automatic cutter, optional stacker
Interface and connectivity Standard: Gigabit Ethernet (1000Base-T) port, FireWire (IEEE-1394a compliant), EIO Jetdirect
accessory slot. Optional: HP Jetdirect print servers
Control panel Monochrome, illuminated and graphical LCD display area; 2 LEDs: Power, Status; 8 keys: Power, Reset,
Form Feed and Cut, Cancel, Up, Down, Back, Select; 1 basic On/Off buzzer
Printer management HP Embedded Web Server
Drivers included DJ4520 1067 mm: HP-GL/2, HP-RTL Windows® drivers, support for Citrix® XenApp and Citrix®
XenServer environments, HP PCL 3 GUI driver for Mac OS X; DJ4520ps 1067 mm: HP-GL/2, HP-RTL,
PostScript® drivers for Windows®, HP PCL 3 GUI, PostScript® drivers for Mac OS X, support for
Citrix® XenApp and Citrix® XenServer environments
Software HP Designjet Windows® drivers, HP Designjet Mac drivers, ICC profiles
Operating systems compatibility Windows Vista® (32/64-bit), Microsoft® Windows® Server 2008 (32/64-bit), XP Home and
Professional (32/64-bit), Server 2003 (32/64 bit), Mac OS X v10.4, v10.5
Network operating systems
compatibility
Windows Vista® (32/64-bit), Microsoft® Windows® Server 2008 (32/64-bit), XP Home and
Professional (32/64-bit), Server 2003 (32/64-bit), Mac OS X v10.4, v10.5, Linux
Minimum system requirements Microsoft® Windows®, Linux: Intel® Pentium® 4 (1 GHz), 512 MB RAM, 2 GB available hard disk
space. Mac OS X v10.4 or higher: PowerPC G3 or Intel® Core Processor, 512 MB RAM, 1 GB
available hard disk space
Recommended system requirementsMicrosoft® Windows®, Linux: Intel® Pentium® 4 (1 GHz), 1 GB RAM, 2 GB available hard disk
space. Mac OS X v10.4 or higher: PowerPC G4, G5, or Intel® Core Processor, 1 GB RAM, 2 GB
available hard disk space
Power Requirements: Input voltage (auto ranging) 100 to 127 VAC (+/- 10%), 6 A; 220 to 240 VAC (+/-
10%), 3 A; 50/60 Hz (+/- 3 Hz). Supply: Internal: built-in universal power supply. Consumption: 500
watts maximum (active), 105 watts maximum (standby), 63 watts maximum (powersave), less than 1
watt maximum (off)
Dimensions (w x d x h) Out of package: 1930 x 800 x 1350 mm. Packaged: Printer: 2130 x 775 x 1320 mm; Multiroll:
1420 x 480 x 510 mm
Weight Out of package: 185 kg. Packaged: Printer: 227.3 kg; Multiroll: 36 kg
Operating environment Operating temperature: 5 to 40º C. Recommended operating temperature: 15 to 30º C. Operating
humidity: 20 to 80% RH. Operating humidity recommended: 25 to 75% RH. Storage temperature: -20
to 55º C. Storage humidity: 0 to 95% RH. Noise level per ISO 9296: sound power: LwAd 7 B(A)
(active), 5.7 B(A) (standby). Sound pressure: LpAm 53 dB(A) (active), 38 dB(A) (standby)
Certifications Safety: EU (LVD and EN60950-1 compliant), Russia (GOST). EMC certifications: Compliance for Class
A ITE products: EU (EMC Directive)
Warranty Two-year limited hardware warranty. Warranty and support options vary by product, country and local
legal requirements.
CM767A Printer, printer stand and bin, printheads
(x 8), printhead cleaners (x 8), introductory ink
cartridges, roll module, user maintenance kit,
quick reference guide, setup poster,
documentation and drivers software, power cord
CM768A HP Designjet 4520ps 1067 mm Printer
with embedded Adobe PostScript
Accessories
CN088A Serif PosterDesigner Software Pro for HP
Designjet Printers
Q5677A HP Designjet 4500 220V Stacker
CM973A HP Designjet 512 MB Memory Upgrade
Q5680A HP Designjet High Speed USB 2.0 Card
J7961G HP Jetdirect 635n IPv6/IPsec Print Server
CM770A HP Designjet 4520 Scanner
CN455A SCP reprocontrol for HP (2 printers)
Ink supplies
C5054A HP 90 Black Printhead and Printhead
Cleaner
C5055A HP 90 Cyan Printhead and Printhead
Cleaner
C5056A HP 90 Magenta Printhead and Printhead
Cleaner
C5057A HP 90 Yellow Printhead and Printhead
Cleaner
C5058A HP 90 400-ml Black Ink Cartridge
C5059A HP 90 775-ml Black Ink Cartridge
C5061A HP 90 400-ml Cyan Ink Cartridge
C5063A HP 90 400-ml Magenta Ink Cartridge
C5065A HP 90 400-ml Yellow Ink Cartridge
Media supplies
CG891A HP Recycled Bond Paper-1067 mm x
45.7 m (42 in x 150 ft)
Q8751A HP Universal Inkjet Bond Paper-914 mm
x 175 m (36 in x 574 ft)
CG885A HP Cockle-free Coated Paper-1067 mm
x 45.7 m (42 in x 150 ft)
C3868A HP Natural Tracing Paper-914 mm x
45.7 m (36 in x 150 ft)
Service & support
UN397E HP Care Pack, Next Business Day
Hardware Support, 3 years
UN396E HP Care Pack, Next Business Day
Hardware Support, 4 years
UN395E HP Care Pack, Next Business Day
Hardware Support, 5 years
UN390E HP Care Pack, 4 Hour Response Time
13x5 Same Day On-site Hardware Support, 3
years
UN391PE HP Care Pack, Post Warranty Next
Business Day Hardware Support, 1 year
UN385PE HP Care Pack, Post Warranty 4 hour
13x5 Same Day On-site Hardware Support, 1
year
H7604E Standard Installation
H4518E Network Installation
For a complete list of supplies, accessories and
services, please refer to
http://www.hp.com/go/designjet
http://www.hp.com/uk
Published in EMEA 05/09 4AA2-4795EEE
