User manual - SR150 2-CHANNEL UNIVERSAL POWER AMPLIFIER
|
P 10
9
T E C H N I C A L D ATA
D I S T O R T I O N
Figures valid for all levels from 0 to 20 V / 8 Ohms.
• Dynamic : TID < 0.01 % (- 80 dB).
• Static : THD < 0.01 % (- 80 dB).
S P E E D
• Slew rate : > 240 V/us
• Rise time : < 260 ns.
N O I S E
• Weighted ASA A : > 100 dB.
D / A C O N V E R T E R
• Using a plugged-in Goldmund Alize4 2-channel D/A module protected against static.
O P E R AT I N G T E M P E R AT U R E
• Room temperature : -30 to +40 degrees Celsius ( -22 to +104 degrees Fahrenheit).
• Internal temperature : +45 to +65 degrees Celsius ( +113 to +149 degrees Fahrenheit).
P O W E R S U P P LY
• Nominal line voltage : 117 or 234 V.
• Input voltage range : +/- 15 %.
• Maximum power consumption : 450 W.
S I Z E A N D W E I G H T
• 44 cm W x 33 cm D x 9 cm H. - Weight : 13 kg net.
WA R R A N T Y
• 3 years parts and labor.
