7050A Operating Manual
AMPLIFIER SECTION
INPUT SECTION CROSSOVER SECTION
SYSTEM SPECIFICATIONS
7050A
Free field frequency response
(+/- 3 dB) 38 Hz…85 Hz
Maximum short term sine wave
SPL output averaged from
45 to 85 Hz, measured in
half space at 1 meter ≥ 100 dB SPL
Maximum peak SPL output with
random pink noise, measured
in half space at 1 meter ≥ 105 dB SPL
Self generated noise level in
free field @ 1 m on axis
(a-weighted) ≤ 15 dB
Harmonic distortion @ 95 dB SPL
at @ 1 m on axis in half space 40 … 85 Hz
2nd ≤ 3 %
3rd ≤ 2 %
Driver, magnetically shielded 200 mm (8”)
Weight 15 kg (33 lbs)
Dimensions
Height 410 mm (16 1/8”)
Width 350 mm (13 3/4”)
Depth 314 mm (12 3/8”)
7050A
Short term amplifier output
power (Long term output power
is limited by driver unit
protection circuitry) 70 W
Amplifier system distortion
at nominal output
THD ≤ 0.08%
Mains voltage 230 V, 115/230V or 100/200V
according to region
Power consumption (average)
Idle 10 VA
Full output 100 VA
CONTROLS
7050A
Input connector XLR female
pin 1 gnd
pin 2 +
pin 3 –
Input impedance 10 kohm balanced
Input level for 100 dB SPL
output @ 1 m 0…–18 dB (referenced to 1029/2029 output)
7050A
Input sensitivity 0…–18 dB
7050A
Subsonic filter
(18 dB/octave) below 38 Hz
Crossover frequency,
(sub/main channels) 85 Hz
Genelec Document D0045R001. Copyright Genelec Oy 5.2002. All data subject to change without prior notice
