Hot Water Boiler
Automatic - Heavy Duty - Non Pressure
Grindmaster® Coffee Grinders and Brewers • PrecisionBrew™ Brewing Systems • Espressimo® Espresso Machines
Crathco® Hot Beverage Dispensers • Crathco® Cold and Frozen Beverage Dispensers • AMW Coffee and Tea Systems
Tel (502) 425-4776 • Fax (502) 425-4664 • 1-800-695-4500 (USA & Canada only)
P.O. Box 35020 • Louisville, KY 40232 • USA
www.grindmaster.com • email: [email protected]
© Grindmaster Corporation, 1995
PRINTED IN USA
0807 Form # AM-214-02
GPH RECOVERY
Model
Gallon
Draw
Off
Heater
Size
50°F
Inlet
Water
140°F
Inlet
Water
1 Phase
Max.
Amps
815
15
5.5 KW
208V/1PH
13
32
25
7 KW
240V/1PH
18
44
29
830
30
12 KW
30
74
57
850
50
15 KW
38
90
72
Electric Heat
Specify electric service desired. Standard is dual voltage 120/240V
or 120/208V single phase 3 wire (neutral wire required).
Specials: 120/208 Volt
3-PH, 4 Wire
Specify Option 21A
240 Volt
3-PH, 3 Wire
Specify Option 21B
480 Volt
3-PH, 3 Wire
Specify Option 21C
Note: Control circuit is 120 Volt AC. In addition, a ground wire
must be supplied.
Recommended Options
OPT. 79
Extra water faucet, no gage, front or back.
Model
Number
A
B
C
Work
Height
815
18”
15”
11-1/4”
24”
830
21”
16-3/4”
12-1/2”
27”
850
21”
16-3/4”
12-1/2”
32”
FAUCET CLEARANCE 8 1/4” MIN.
ROUGHING-IN DATA
5”
8”
2 1/4”
3 1/2”
1 1/4”
4 1/2”
4 1/4”
3/8” FPT
WATER
INLET
ELECTRICAL
INPUT
2 1/2”
A
C
B
CL
1 1/4”
