2
Gateway 18-inch LCD TV Specifications
www.gateway.com
Connector Types
1 RCA jacks for audio, video, and YP
B
P
R
1 6-pin Din S-terminal for S-Video
1 15-pin D-SUB for RGB
1 F-terminal coax
Video Signal
Type Analog
Polarity Positive
Amplitude 0.7 Vp-p
Sync 0.3 V below video
Frequency H: 15.734 KHz V: 60 Hz (NTSC)
H: 15.625 KHz V: 50 Hz (PAL)
Input impedance 75 ohms
YP
B
P
R
Signal (Component)
Type Analog
Polarity Positive
Amplitude Y: 1 Vp-p, C: 0.286 Vp-p
Sync 0.3 V below video
Frequency Y/P
B
/P
R
H: 15.734 KHz V: 60 Hz (NTSC)
H: 15.625 KHz V: 50 Hz (PAL)
