13

Operating in cold temperatures

The ventilation slide cover (7) is factory set for use of the

chain saw in normal temperatures. It can be changed for

use in temperatures around or below freezing point. In this

case the position of slide cover (7) is reversed to allow the

air entering the carburettor to be first warmed by the engine

to increase the efficiency of the operation.

1. Turn off the engine.
2. Loosen top cover knob (12)

and remove cover (11).

3. Remove air filter (8) and

disengage the choke control

(18) from its grommet in the

cylinder cover (6) and also

remove the idle adjustment

screw cover.

4. Remove the four screws that secure the cylinder cover

(6).Three screws are located in the chamber under the

top cover. The fourth screw is located at the top front left-

hand side of the saw.

5. Remove the cylinder cover (6).
6. Remove the slide cover, turn

it the other way round with the

snow crystal symbol at the

top and the sun symbol at the

bottom and replace the slide

cover in the cylinder cover.

Replace the cylinder cover and

restore all other components in

their original positions.

Operation

WARNINGS.

Always follow the safety instructions given at the front

of this manual. This chain saw must only be used for

cutting wood. It must not be used for cutting other types

of material. Do not use the chain saw as a lever for lifting,

moving or splitting objects.

Do not attach the chain saw to a fixed stand.

Do not attach any devices to the chain saw other than

those specified by the manufacturer.

Helpful hints

Do not force the saw into the cut. Apply only light pressure

whilst running the engine at full throttle.

If the saw chain gets caught in the cut, do not try to

remove it by twisting the guide or pulling forcibly. Use a

lever or wedge to open up the cut so that the saw chain

is freed.
