4 Specifications
Frequency Response:
55Hz to 36kHz,
± 3dB
Sensitivity:
89 dB, 1 watt 1 meter
Min/Max Power (Tube):
75/500 watts per side
Min/Max Power (Solid State): 100/1000 watts per side
Input Impedance:
4 ohms (Nominal)
HF Transducers:
Three Genesis 1” Circular Ribbon
Tweeters (front and two side)
Midrange Transducers:
One Genesis 5” titanium cone
midrange
LF Transducers:
Two Genesis 6.5” aluminium
cone
Controls: Tweeter
level
Monopole/Dipole/Remote Mode
Inputs:
High-level with 5-way binding posts
12v trigger for remote operation
Throughputs:
High-level with 5-way binding posts
Dimensions:
H 14½ “ x W 20½” x D 12”
Weight:
38.5 lbs (17.5kg) per side
Finishes:
Rosewood, Olive Ash or
Pomele Sapele with Satin black;
Standard and custom
automotive paints
