Section 1 — General Information
Generac Air-cooled 7 kW, 12 kW and 15 kW Generators
Generac
®
Power Systems, Inc.
5
1.4 THE
GENERATOR
Exhaust
Enclosure
Oil
Dipstick
Data
Decal
Control
Panel
Fuel
Regulator
Fuel
Inlet
GFCI
Outlet
Oil Filter
Battery
Compartment
Exhaust
Enclosure
Oil Filter
Battery
Compartment
Fuel
Inlet
GFCI
Outlet
Control
Panel
Data
Decal
Oil
Dipstick
Fuel
Regulator
Composite Base
Figure 1.2 – 12 kW/15 kW, V-twin GT-990/760 Engine
Figure 1.1 – 7 kW, Single Cylinder GH-410 Engine
