GX-1501
Introducing the GX Series Passive and Powered Speakers. Listen and hear what you’ve been missing. With clear and accurate output, these powerful 2-
way speakers are loaded with an 8“, 10”, 12” or 15” woofer with matched compression drivers and wide dispersion horn design, offering suburb sound quality and high
wattage capability. The GX Series Powered Speakers have built-in amplifiers and electronic crossovers providing for a speaker/amplifier system ready to deliver your
audio source. The trapezoidal design allows for multiple placements options. Constructed out of ABS impact resistant nylon fiber, the durable, rugged and portable GX
Series Speakers can easily withstand constant load-in/out handling and continue to provide the sound output you demand. Get the sound output of a pro at an amateur price.
GX-1201
Speakers GX-800/801 GX-1000/1001 GX-1200/1201 GX-1500/1501
Power 2-Way 250W 2-Way 400W 2-Way 600W 2-Way 800W
Woofer 8” Woofer with 2” Voice Coil and
40 oz Magnet
10” Woofer with 2” Voice Coil and
40 oz Magnet
12” Woofer with 2.5” Voice Coil and
65 oz Magnet, Aluminum Basket
15” Woofer with 3” Voice Coil and
65 oz Magnet, Aluminum Basket
Driver Pure Titanium Compression Driver
with 1.35” Coil
Pure Titanium Compression Driver
with 1.35” Coil
Pure Titanium Compression Driver
with 1.35” Coil
Pure Titanium Compression Driver
with 1.75” Coil
Linear Frequency Response Between 70 Hz - 20 kHz Between 60 Hz - 20 kHz Between 45 Hz - 20 kHz Between 45 Hz - 20 kHz
Sensitivity (Passive Only) 97 db / 1 W / 1 M 97 db / 1 W / 1 M 97 db / 1 W / 1 M 99 db / 1 W / 1 M
Inputs (Powered Only) Switchable Mic/Line Inputs
Separate Balanced Mic Input with
Gain and Tone Control
Separate Balanced Mic Input with
Gain Control
Dual Mic Inputs (XLR and 1/4”
Stereo) with Separate Gain Control
Dual Mic Inputs (XLR and 1/4”
Stereo) with Separate Gain Control
Weight (Powered / Passive) 31 lbs - 14.5 kgs / 27.5 lbs - 12.5 kgs 43 lbs - 19.5 kgs / 35.2 lbs - 16 kgs 55 lbs - 25 kgs / 48.4 lbs - 22 kgs 67 lbs - 29.5 kgs / 57.2 lbs - 26 kgs
GX-1001
FEATURES
GX-801
*Specifications subject to change without notification for improvement
Speakers GX-800/801 GX-1000/1001 GX-1200/1201 GX-1500/1501
Woofer Magnet Weight 40 oz 40 oz 65 oz 65 oz
Woofer Voice Coil 2” / 50.8 mm 2” / 50.8 mm 2.5” / 65 mm 3” / 72 mm
Woofer RMS Wattage 70 W 120 W 150 W 180 W
Woofer Peak Wattage 150 W 250 W 400 W 550 W
Compression Driver Magnet
Weight
13 oz 13 oz 13 oz 20 oz
Compression Driver
Diaphragm Size
35 mm 35 mm 34 mm 34 mm
Compression Driver
RMS Wattage
30 W 60 W 100 W 120 W
Compression Driver
Peak Wattage
100 W 150 W 200 W 250 W
Crossover Specification 3.5 kHz, 12 db / Oct 2.8 kHz, 12 db / Oct 2.5 kHz, 12 db / Oct 2.2 kHz, 12 db / Oct
Total RMS Wattage 100 W 180 W 250 W 300 W
Total Peak Wattage 250 W 400 W 600 W 800 W
SPEciFicATionS
Portable ABS Molded Speakers
(All Passive models come
with Speakon connections)
All Units: Wide Dispersion Horn Design • Recessed Smooth Molded Handle • Speakon (Passive) or XLR (Powered) Input/Output Connectors
ABS Impact Resistant Nylon Fiber Cabinet • Nominal Horn Dispersion: 30” x 60” • 35mm Stand Mount Hole • Trapezoidal Design • Woofer Impedance: 8 Ohms (Passive Only)
Powered Only: Aux RCA Input • Volume Output Control • Built-in Amplifier with Electronic Crossover • Tone/EQ Controls
Mono-Power Amplifier • Power Guided Clip Alert LED • Toroidal Power Transformer
