11

ITEM PART

NO. QTY. DESCRIPTION

1

0F9080

1

LOAD

DISCONNECT

ENCLOSURE

2

0F9081

1

LOAD DISCONNECT ENCLOSURE COVER

3

0C3211T

2

RELAY 40A @ 300VAC DPDT

4

0C3211U

2

RELAY DPDT 24VAC 5A 8 PIN

5*

0C3211G

2

SOCKET RELAY 8 PIN

6*

0F9072

1

BLOCK TERM 10MM 8 POS MOLEX

7

074908

4

SCREW HHTT M5-0.8 X 10BP

8

0C2265

4

SCREW PHTT M5-0.7 X 12 ZYC

9

0C2695

4

SCREW PHTT M4-0.7 X 20 ZYC

10

0C2323

3

SCREW PHTT #6-32 X 5/8 ZYC

11

0F9151

1

DECAL,

FIELD

WIRING

12

0F9152

1

DECAL, FRONT COVER

13

0F9148

1

HARNESS, POWERMASTER (NOT SHOWN)

* STRUCTURED ON HARNESS

Section 5 — Exloded Views & Parts Lists

Assembly - Drawing No. 0F9110-A
