Goodman Mfg GDH81155CXCB - Manual (Page 5)

Cabinet Assy
Ref.
No: Part
No:
Description:
Ref.
No: Part
No:
Description:
Image 1:
FURNACE BOTTOM 14" (M1, M2, M3, M4) 0121F00183DG 11
FURNACE BOTTOM 17.5" (M5, M6) 0121F00190DG 11
FURNACE BOTTOM 21" (M7, M8) 0121F00191DG 11
TOP 14" (M1, M2, M3, M4) 0121F00141DG 31
TOP 17.5" (M5, M6) 0121F00142DG 31
TOP 21" (M7, M8) 0121F00143DG 31
BLOWER DOOR, 14" (M1, M2, M3, M4) 0121F00122DGS 41
BLOWER DOOR, 17.5" (M5, M6) 0121F00123DGS 41
BLOWER DOOR, 21" (M7, M8) 0121F00124DGS 41
TRANSFORMER 120V TO 24V, 40 VA B1141605 51
PRESSURE SWITCH 0.60" WC (M1, M2, M5, M6) B1370142 61
PRESSURE SWITCH -0.70" WC (M3, M4, M7, M8) B1370158 61
VIEW PORT BUSHING-BLOWER DOOR (QTY 2) B1392139 71
INNER BLOWER DOOR 14" (M1, M2, M3, M4) 0121F00185 81
INNER BLOWER DOOR 17.5" (M5, M6) 0121F00192 81
INNER BLOWER DOOR 21" (M7, M8) 0121F00193 81
CONTROL ACCESS DOOR, 14" (M1, M2, M3, M4) 0121F00118DGS 91
CONTROL ACCESS DOOR, 21" (M7, M8) 0121F00120DGS 91
CONTROL ACCESS DOOR,17.5" (M5, M6) 0121F00119DGS 91
CHIMNEY TRANSITION TOP 4023500 101
J-BOX COVER 4015502 111
J-BOX 4014502 121
UNIVERSAL BUSHING WITH SLICE 0163F00001 131
INTERLOCK SWITCH B1370818 141
12-PIN WIRE HARNESS ASSY 0259F00056 NS
HYBRID WIRE KIT 0259F00060 NS
IGNITOR WIRE HARNESS ASSY 0259F00058 NS
PRESSURE SWITCH HOSE A3468601 NS
Expanded Model Nomenclature
M1 - GDH80453AXCA
M2 - GDH80453AXCB
M3 - GDH80703AXCA
M4 - GDH80703AXCB
M5 - GDH80904BXCA
M6 - GDH80904BXCB
M7 - GDH81155CXCA
M8 - GDH81155CXCB
5 RP-563A www.goodmanmfg.com
