SS-GPCC www.goodmanmfg.com 3
P
RODUCT
S
PECIFICATIONS
S
PECIFICATIONS
PCC090-3A PCC090-4A PCC120-3A PCC120-4A
Cooling Capacity
Total BTU/h
86,000 86,000 116,000 116,000
Sensible BTU/h ¹ 63,600 63,600 85,000 85,000
EER ² 10.3 10.3 10.3 10.3
IPLV ³ 10.7 10.7 10.7 10.7
Indoor Blowers (2)
Type
Belt Belt Belt Belt
Wheel (D x W) 12” x 12” 12” x 12” 12” x 15” 12” x 15”
Indoor Nominal CFM 3,000 3,000 3,800 3,800
Horsepower 1½ 1½ 3 3
Evaporator Coil (1)
Face Area (ft²)
11.2 11.2 14 14
Rows Deep/ Fins per Inch 3/ 16 3/ 16 3/ 16 3/ 16
Tube Diameter - Material ⅜” - Copper ⅜” - Copper ⅜” - Copper ⅜” - Copper
Filter Size (ft²) / Quantity –– –– 16 x 25 x 2 / 3 16 x 25 x 2 / 3
25 x 25 x 2 / 3 25 x 25 x 2 / 3 20 x 25 x 2 / 3 20 x 25 x 2 / 3
Condenser Fans (2) / Coil (1)
Horsepower
½ ½ ½ ½
Fan Diameter 24” 24” 24” 24”
Outdoor Nominal CFM 5,500 5,500 6,400 6,400
Face Area (ft²) 15.6 15.6 23.8 23.8
Rows Deep/ Fins per Inch 2/ 21 2/ 21 2/ 21 2/ 21
Tube Diameter - Material ⅜” - Copper ⅜” - Copper ⅜” - Copper ⅜” - Copper
Electrical Data
Voltage-Phase
208/230-3 460-3 208/230-3 460-3
Compressor RLA/ LRA 12.5/ 88 5.9/ 44 17.4/ 123 6.8/ 49.5
Indoor Blower FLA 4.2 2.0 8.4 4.2
Outdoor Blower FLA 2.6 1.3 2.6 1.3
Min. Circuit Ampacity 4 38.1 18.2 54.5 22.5
Max. Overcurrent Device 5 60 amps 30 amps 70 amps 35 amps
Operating Weight (lbs) 980 980 1,270 1,270
Ship Weight (lbs) 1,000 1,000 1,290 1,290
¹ Sensible capacity is gross, with no deduction for indoor motor heat
² BTU/Watt @ 80/ 67° F inside; 95° F outside air
³ IPLV = Integrated Part Load Valve
4 Wire size should be determined in accordance with National Electrical Codes. Extensive wire runs will require larger wire sizes.
5 HACR breakers may be used in place of fuses up to 60 amps
