Page 6 Auto Series Brewer Manual
SPARE PARTS LIST
Item No. Part No. Description Item No. Part No. Description
1 73035 Water Tank 33A 73187-1 Decal, Main Front AT-AP, AT-TC
2A 73252 Clamp Hose, Nylon 1/2" ID 33B 73187 Decal, Main Front W/Switch Power AT-AP, AT-TC
2B 07327 Clamp, Black 5/8" 34 06491 Deflector, Spray HD
3 71155 Tubing, 5/16"ID x 1/2"OD Silicone 35 06490 Nozzle, Spray HD
4 73173 Heat Exchanger Inside Tank 36 07220 Nut, Lock Palnut Spray HD
5 70818 Element, Heating 1400W 120V 37 70341 Elbow, Silicone 90 deg
70820 Element, Heating 2500W 240V 38 73242 Hole Plug
73222 Element, Heating 1780W 120V 39 71093 Pipe Adapter
6 73037-1 Inlet Tube Assembly 40 73179 Timer Relay, 120V
7 73186A Cover, Tank W/Bracket, Thermostat 73251 Timer Relay, 230V
8 61143 Nut, Pipe Jam 1/8" NPT 41 73114 Bracket, Panel Spray HD
9A 73176 Fitting Brass 1/4"MFL x 3/8"MPT 42 73003 Top Cover SS, AT-AP, AT-3WR
9B 73177 Fitting Brass 1/4"MFL x 3/8"NPT 43 71607 Panel, Pour-Over Lid
10 05826 Tubing, 3/8"ID x 5/8"OD Silicone 44 71529 Wire Hinge, Pour-Over Lid
11 73033 Elbow Brass, 1/8" NPT 3/8" Barb 45 73008 Nut Slotted Hex SS (size M20x1.5)
12 71147 Grommet, White Silicone 46 73010 Pan, Receiving
13 61243 Grommet, Dump Valve 47 73175 Assy, Water Line to Faucet
14 73178 Fitting, 1/4"MFL x 3/8" Barb 48 73188A Top Body Assemply AT-AP, AT-TC
15 73234 Tube, Inner Braided Silicone 49 73191 Panel, Back AT-AP, AT-APE
16 60550 Clamp Hose, Stainless 50 73232 Valve Inlet 120V, 50/60Hz
17 73036 Thermostat Regulating 73233 Valve Inlet 230V, 50/60Hz
18 62237 T-Stat, Hi-Limit, 120V Models 51 73021 Bracket, Tank Base AT-AP, AT-APE
100523 T-Stat, 1/2" Manual Reset 230V Models 52 73192 Panel Center SS. AT-AP, AT-APE
19 62238 Bracket, Hi-Limit 120V Models 53 73190 Panel, Back AT-TC, AT-2W, AT-3WR
100524 Bracket, Hi-Limit Manual Reset 230V Models 54 73213 Base Tank
20 73095 Bracket, Water Tank 55 73185 Panel Center SS. AT-TC, AT-2W, AT-3WR
21 73057 Gasket, Tank O-Ring 56 73029 Base Cover Panel, AT-2W
22 73096 Thermostat Clip Lock 57A 73217-1 Decal, Main Front AT-2W
23 73028 Leg, Support 57B 73217 Decal, Main Front W/Switch Power AT-2W
24 73026 Base Welded 58 73031 Panel, Warmer Top AT-2W
25 73024 Base Cover Panel, AT-AP, AT-AC 59 73001 Bracket, Warmer
26 73027 Airpot Stopper 60 73002 Plate, Warmer
27A 73183 Rail Brew, RH. Assembly 61 13029 Heater, Warmer 120V, 100W
27B 73182 Rail Brew, LH. Assembly A535-028 Heater, Warmer 220V, 100W
28 71952 Brew Basket 62 73004 Top Cover SS, AT-2W
29 73249 Pressure Faucet 63 73218A Top Body Assemply AT-2W
30 62436 Ready Light, Green 120V 64 73079 Base Welded AT-3WR
61125 Ready Light, Green 230 65 73080 Base Cover Panel, AT-3WR
31 70445 Brew Switch 66 73078 Panel, Warmer 3RD, AT-3WR
32A 73058 Switch Warmer Lighted 230V 67A 73181-1 Decal, Main Front AT-3WR
73059 Switch Warmer Lighted 120V 67B 73181 Decal, Main Front W/Switch Power AT-3WR
32B 73194 Switch Power - Optional 68 73218A Top Body Assemply AT-3WR
69 61237 Fitting Assembly 1/4MFL x 3/4Hs Brass
Not shown:
61530 Power Cord, 120V
61453 Power Cord, 230V
