BT-359 GPS
3. CHANGING THE BATTERY
1. Slide battery cover lock into the open UNLOCK position and lift up carefully on battery cover from
lock end at seam where cover meets the main GPS housing.
2. Use the pull tab to lift out Li-ion battery.
3. Replace battery making sure that the battery contact on the bottom side of battery touch the
contacts on the BT-359 within the battery compartment. (Pull tab should at the same end as the
battery cover lock)
4. Carefully hook the two catches of the battery cover to the GPS housing and gently close battery
cover.
5. Place battery cover lock into the “locked” position.
4. GPS FUNCTIONS
Turning the BT-359 ON / OFF
BT-359’s Power Button
Power ON:
Press the power button for 1 second until the power LED becomes lit.
Power OFF:
Press the power button 1 second until the power LED goes off.
Pull Tab
Cover Hooks Here
