Generac
®
Power Systems, Inc. 45
ITEM
PART NO. QTY. DESCRIPTION
1
C2368
1
BASE, MOUNTING
2
53407
1
GROUND CABLE
3
46911
4
MOUNT, (RUBBER)
4
25017
6
CAPSCREW, HEX HD.-3/8"-16
X 1/2"
5
22237
6
LOCK WASHER-3/8"
6
22129
10
LOCK WASHER-M8
7
A6479
1
SKID, RUBBER MOUNT
8
77603
2
SAFETY BOLT 5/16"-18 X 3
1/2"
9
22259
2
NUT, HEX-5/16"-18
10
52858
6
NUT, FLANGED LOCK-M8-1.25
11
51730
2
CAPSCR. HEX HD.-M8-1.25 X
60MM
12
29459
2
SPRING, BELT TENSION
13
75215
2
WASHER, SPRING CNTR.
14
73146
4
SLIDE (NYLON)
15
75209
2
SUPPORT, NYLON SLIDE
16
A8341
1
MANIFOLD, EXHAUST
17
90239
1
GASKET, EXHAUST
MANIFOLD
18
40976
2
SOCKET HD. CAPSCR.,-M8-
1.25 X 20 LG.
19
A6858
1
GASKET, COLLECTOR PAN
20
A8614
1
SKID, RUBBER MOUNT
21
75224-B
1
PULLEY, ENGINE
22
73106-B
1
PULLEY, ALT.
23
75216
1
BELT (POLY V 4L)-40"
24
49451
1
WASHER, PULLEY RETAINER
25
42633
1
CAPSCR., SOCKET HD. 3/8"-24
X 1" (GRADE 5)
26
39253
3
CAPSCR., HEX HD.-M8-1.25 X
20
27
A8250
1
CAPSCR., HEX HD.-3/8"-24 X 2"
28
56893
14
CRIMPTITE-#10-24 X 1/2"
29
A7837
1
BRACKET, LP REGULATOR
30
C1320
1
HOUSING, BLOWER
31
63036
3
CRIMPTITE-#8-18 X 1/4"
32
A8694
1
SCREEN, SLIDE PAN
33
A8726
1
GASKET, BLOWER / PAN
34
75242
4
SPRING, GENERATOR SET MT
35
62684
1
GROUNDING LUG
ITEM
PART NO. QTY. DESCRIPTION
36
A4456
2
3/8" SPECIAL LOCK WASHER
37
75211
1
REGULATOR, GAS FUEL
38
A6894
1
MANIFOLD, LP
39
A2666
1
SOLENOID, GAS FUEL
40
61696
1
BARB, 90 DEG. ½" X 3/8" NPT
41
79246
2
CAPSCR., HEX HD.-M6-1.0 X 16
42
22145
8
FLAT WASHER-M8-5/16"
43
38150
3
FLAT WASHER-#8
44
A8010A
1
GASKET, BLOWER HSNG
45
77643
1
EXHAUST PIPE GASKET
46
75237
4
WASHER, SPRING RETAINER
47
75763-A
1
BOOT, BATTERY CABLE
48
90859
1
EXHAUST COVER PLATE
49
74994
10.5" HOSE, ½ ID PETROLEUM
50
A8594
1
PAN, SLIDE
51
23762
2
SHAKEPROOF WASHER
52
23152
2
CAPSCR., HEX HD.-3/8"-16 X
3/4"
53
23762
1
SHAKEPROOF-#10
54
C3766
1
¾" NPT PLUG
55
22131
1
FLAT WASHER-M10
56
57822
2
#8 HOSE CLAMP
57
81105
2
NUT, FLANGE-5/16"-18
(SPECIAL)
58
66849
2
SCREW, TAPTITE M5-0.8 X 16
LG.
59
86729
1
STARTER CONTACTOR
60
A8010
1
GASKET, BLOWER HSNG
62
10-74260
1
STARTER CABLE
63
22127
2
HEX NUT-1/4"-20
64
22097
4
LOCK WASHER-1/4"
65
22264
2
LOCK WASHER-M4
66
22471
2
HEX NUT-#8-32
67
A8531
1
PLATE, BLOWER SIDE
68
A8407
1
GASKET, BLOWER SIDE
69
22473
1
FLAT WASHER ¼"
70
38750
2
M6-1.0 X 30 HHCS
71
49813
2
M6-1.0 HEX NUT
72
26915
2
CLOSE NIPPLE ¾" NPT
73
26307
1
90 DEG. ¾" STREET ELBOW
74
45771
3
M8-1.25 HEX NUT
Appendix 4 — Exploded Views and Parts Lists
PRIMEPACT 50 Recreational Vehicle Generator
Base and Pulleys (Model 04164-0) – Drawing No. C3878-A
