Make sure all parts are properly tightened each time the resistance system is used. Replace any worn parts imme-
diately. The resistance system can be cleaned with a damp cloth and a mild, non-abrasive detergent. Do not use
solvents.

ADJUSTING THE RESISTANCE

Slide the Bands (3) onto the Band Axles (1). Secure
the Bands with the four Spring Clips (4).

WARNING:

Always make sure

there are an equal number of Bands (3) on each
set of Band Axles (1). Always secure the Bands
with the Spring Clips (4).

ADJUSTMENTS

3

4

1

3

4

3

2

1

3

3

4

5

4

2

PART LIST/EXPLODED DRAWING—

R1005A

Model No. GGMC0724.0

1

4

Band Axle

2

4

Bushing

3

2

Band

4

4

Spring Clip

5

1

Sensor

#

1

User’s Manual

Note: “#” indicates a non-illustrated part.
Specifications are subject to change without notice.

Key No. Qty.

Description
