Know your product
1. Handle
2. Pressure switch cover
3. On/off switch
4. Direct outlet valve
5. Direct outlet pressure gauge
6. Regulating knob
7. Regulated outlet valve
8. Regulated outlet pressure gauge
9. Safety valve
10. Non-return valve
11. Drain cock
12. Air tank
13. Wheel (x 2)
14. Safety shield
15. Oil filling cap
16. Air filter assembly
17. Oil level glass
18. Oil drain plug (not shown)
9
12
14
16
13
17
9
5
1
3
2
7
10
8
11
15
6
4
