FORM # 36E & 680 Fryers Parts (Rev 2)
GARLAND PARTS IDENTIFICATION
Heavy Duty Fryers
Model: 36ES21
ITEM
PART #
DESCRIPTION
MODEL
QUANTITY
36ES1
1
1027600
Leg Retainer 6” (Std.)
4
2
1150502
Bullet Legs
4
3
1027801
Swivel Caster C/W Brake
2
1027800
Swivel Caster Less Brake
2
4
2671600
Catch-Double Roller #603-2G
1
5
1211903
Control Panel
1
6
1212199
Main Top Assembly
1
7
1193900
Terminal Block - 3 Pole-Hi Voltage
Up to January 1, 2001
1
2694801
Export/Domestic Terminal Block (4)
From January 1, 2001
1
8
1143900
LCH Safety Limit Control
1
1143902
Stuffing Box #4650-002
1
9
G01499-1
Ground Terminal 105A Large SLU-70
1
10
G2455A2
Element Bottom 208V, 5.6KW
1
G2455A1
Element Bottom 240V, 5.6KW
1
1073796
Bottom Element 460V, 5.6 KW
1
11
G02697-A2
Top Element 208V, 4.8KW W/Clamps
3
G02697-A1
Top Element 240V, 4.8KW W/Clamps
3
1073896
Element 460V, 4.8KW
3
12*
CK161
Tube Clamp Assembly Kit
8
13
G2470-1-9
Tie Bar Support
1
14
G01864-1
Toggle Switch
1
15
G01296-1
Pilot Red 240V
1
G01296-2
Pilot Amber
1
16
1637002
Main Contactor Pole 240V
2
17*
G02504-460
Transformer 460V (High Voltage Only)
1
18
1073900
Regulating Thermostat
1
19
G02716-1
Dial - (Universal) Small Shaft
1
G02725-20
Dial Insert (OFF/200°F/375°F)
1
20*
G2432-1
Basket R/H
1
21*
G2432-2
Basket L/H
1
22
G2433A1
Screen Assembly Nickel
1
23
G2435-01-9
Frytank Assembly
1
24
G2452-1-9
Element Clamp
1
25
G2941-1P
Valve 1” Gate - Plated
2
26
1210901
Door Panel Stainless Steel
1
27
1210996
Door Liner Assembly
1
* NOT ILLUSTRATED
RECOMMENDED STOCK PART
