Grandstream Networks GXV350X - Manual (Page 4)

Grandstream Networks, Inc. 2011 P a g e | 3
3. When the Add Camera dialog box is displayed, you can do the following:
a. In the properties section (see Fig. 4),
enter the name of the camera (this
can be any name you want to
identify the camera with).
b. Enter the IP address of the IP
Camera or Video Encoder
c. Enter the port number of your
selected device (By default it’s 80)
d. Enter the Username and
Password of the selected device.
Fig.4: Properties section in Add Camera Dialog Box
4. Grandstream IP camera or Video Encoder video streaming will be displayed on go1984 under the
image tab (see Fig. 5)
Fig.5: Video Streaming of a Grandstream IP Camera or a Video Encoder
NOTE: The Video Encoder GXV3504 can connect 4 Analog Cameras. The Go1984 will choose by default
the first channel. So if you would like to choose one of the other channels then you need add the video
encoder first then access to its video properties and change the Channel value to:
-
“1”: Second analog port
- “2”: Third analog port
- “3”: Fourth analog port
References:
For more information about the Grandstream IP Cameras and other products capabilities, please visit
http://www.grandstream.com or contact us at [email protected]
For more information about Logiware go1984 software please refer to
http://www.go1984.com .
