TIPS FOR THE ASSEMBLY OF
YOUR NEW MANTEL
• Before you begin assembly, locate the instructions and hardware. Take out all the parts and
compare them to the diagrams below. Be sure you have all the parts and can identify them.
• A helping hand is always good. Assemble your mantel with an adult assistant if possible. Some
pieces are heavy and will need to be held by a helper. Assembly time will take approximately
30-60 minutes.
TOP 1PC
ESPRESSO: ZZ.258E.01
WHITE: ZZ.258W.01
OAK: ZZ.258OK.01
BASE 1PC
ESPRESSO: ZZ.258E.02
WHITE: ZZ.258W.02
OAK: ZZ.258OK.02
UPPER FACING PANEL 1PC
ESPRESSO: ZZ.258E.07
WHITE: ZZ.258W.07
OAK: ZZ.258OK.07
ANTI-TIP DEVICE 2 SETS WINGNUT AND LOCK WASHER
2PCS 2PCS 4PCS 4PCS 17PCS 17PCS 4PCS
LEFT FRONT
PANEL 1PC
ESPRESSO:
ZZ.258E.03
WHITE:
ZZ.258W.03
OAK:
ZZ.258OK.03
INSIDE
VIEW
OUTSIDE
VIEW
FIREBOX SHELF 1PC
ESPRESSO: ZZ.258E.09
WHITE: ZZ.258W.09
OAK: ZZ.258OK.09
LEFT SIDE
PANEL 1PC
ESPRESSO:
ZZ.258E.04
WHITE:
ZZ.258W.04
OAK:
ZZ.258OK.04
RIGHT FRONT
PANEL 1PC
ESPRESSO:
ZZ.258E.05
WHITE:
ZZ.258W.05
OAK:
ZZ.258OK.05
RIGHT SIDE
PANEL 1PC
ESPRESSO:
ZZ.258E.06
WHITE:
ZZ.258W.06
OAK:
ZZ.258OK.06
LOWER FACING PANEL 1PC
ESPRESSO: ZZ.258E.08
WHITE: ZZ.258W.08
OAK: ZZ.258OK.088
