Page 18 SKU 96155 for technical questions, please call 1-800-444-3353.
PARTS LIST/dIAGRAM - fuEL TANk
Part description Q’ty Part description Q’ty
1 Fuel Filler Cap Assy. 1 8 Fuel Tank 1
2 Fuel Filler Cap 1 9 Fuel Tank Cushion 2
3 Foam 1 10 Washer (10.5x30x1) 1
4 Packing Ring 1 11 Stud 1
5 Pipe Clamp (12.8) 1 12 Bolt (M6x12) 2
6 Pipe Clamp (10.8) 3 13 Bracket 1
7 Outlet Pipe (I) 2
IMPORTANT
when ordering parts from the above Parts List, make sure to specify the following:
The PART NuMbER listed to the left of the part description. a.
The NAME Of THE PARTS LIST from which you are ordering (located at the top of this page). b.
