Identification – Grizzly G0621 User Manual
Page 7
G0621 Wood/Metal Bandsaw
-5-
A. Blade Tension Handle
B. Upper Wheel Cover
C. Blade Guide Elevation Handwheel
D. Blade Tension Scale
E. Blade Tracking Knob
F. Blade Guide Elevation Lock Knob
G. Motor Switch
H. Speed Dial
I. Power Switch
J. Fence
K. Upper Blade Guide Assembly
Identification
G
A
D
J
M
I
S
E
Q
K
L
N
O
H
R
B
C
F
P
T
U
L. Miter Gauge
M. Table Tilt Lock Knob (1 of 2)
N. Rear Table Support Lock Knob
O. Lower Wheel Adjustment Hub
P. Lower Wheel Cover
Q. Motor
R. Belt Tension Lock Nut
S. Motor Junction Box
T. Dust Hose Access Hole
U. Blade Guard
