SPECIFICATIONS
GENERATOR Model 2010 Model 4164
Rated Maximum Continuous Power Capacity 4800 Watts 4500 Watts
Rated Voltage 120 120
Rated Maximum Continuous Load Current
120 Volts 40 Amps 37.5 Amps
240 Volt Configurable Yes (20 Amps) Yes (18.75 Amps)
Main Line Circuit Breakers 30 & 20 Amp 30 & 20 Amp
Phase 1 1
Number of Rotor Poles 2 2
Rated AC Frequency 60Hz 60Hz
Power Factor 1 1
Engine RPM
2571 2571
Rotor RPM 3600 3600
Unit Weight 198 Pounds 200 Pounds
Dimensions (L” x W” x H”) 25.5 x 18.9 x 16.75 25.5 x 18.9 x 16.75
ENGINE Model 2010 Model 4164
Type of Engine GENERAC OHVI GENERAC OHVI
Number of Cylinders 1 1
Rated Horsepower 15 15
Displacement 407cc 407cc
Cylinder Block Aluminum w/Cast
Iron Sleeve
Aluminum w/Cast
Iron Sleeve
Valve Arrangement Overhead Valve Overhead Valve
Ignition System Solid-state w/Magneto Solid-state w/Magneto
Governor System Mechanical Fixed Speed Mechanical Fixed Speed
Compression Ratio 8.6:1 8.6:1
Starter
12 Vdc 12 Vdc
Oil Capacity Including Filter Approx. 1.5 Qts. Approx. 1.5 Qts.
Fuel Consumption
Gallons per hour
10% Load
50% Load
100% Load
Gasoline
0.32
0.46
0.76
LPG
047
0.72
1.25
