TR-1 Gladiator LCD Heading Display
Installation and User Guide
Introduction:
The TR-1 LCD display connects to the TR-1 Gladiator Autopilot. It
displays current heading, and displays the current autopilot mode. In
addition it allows the operator to command a new desired heading or
command a rate of turn. With an optional rudder reference indicator;
purchased separately, the display will show rudder position.
The large easy to read transfl ective static LCD display with an anti-
refl ective coating gives you a clear view of the screen from any
angle on the boat or in glaring sunlight and is backlit for easy night
vision.
An optional mounting panel is available. See Figure 2-a. This panel
will allow you to fl ush mount a handheld, and mount the deckmount
On/Off switch, in addition to the LCD Display.
Figure 1-a
Figure 2-a
Thank you for purchasing the TR-1 Gladiator Display. This guide
contains an explanation on how to install and use your new TR-1 Display.
Please be sure to read this instruction manual fully to familiarize
yourself with the features and proper installation and operation of
this display.
Page 1
