G0470 parts list – Grizzly G0464 User Manual
Page 33
Model G0464/G0465/G0467/G0468/G0470 Air Compressors
-
31
-
G0470 Parts List
REF PART #
DESCRIPTION
REF PART #
DESCRIPTION
1
PB105M
HEX BOLT M6-1 X 55
38
P6204
BALL BEARING 6204
2
PLW03M
LOCK WASHER 6MM
39
P0470039
ROTOR
3
P0470003
CYLINDER HEAD
40
P6202
BALL BEARING 6202
4
P0470004
EXHAUST ELBOW
41
P0470041
STATOR
5
P0470005
CYLINDER HEAD GASKET
42
P0470042
REAR MOTOR COVER
6
P0470006
VALVE ASSEMBLY
43
P0470043
FAN
7
P0470007
VALVE PLATE
44
P0470044
HEX BOLT M5-.8 X 120
8
P0470008
VALVE PATCH
45
PLW01M
LOCK WASHER 5MM
9
P0470009
PISTON
46
P0470046
GASKET
10
P0470010
CYLINDER GASKET
47
PR02M
EXT RETAINING RING 14MM
11
P0470011
CYLINDER
48
P0470048
COVER
12
PSB31M
CAP SCREW M8-1.25 X 25
49
PB95M
HEX BOLT M5-.8 X 16
13
PLW04M
LOCK WASHER 8MM
50
PW03M
FLAT WASHER 6MM
14
P0470014
CYLINDER GASKET
51
P0470051
QUICK CONNECT-FEMALE
15
P0470015
COMPRESSION RING
52
P0470052
PRESSURE GAUGE
16
P0470016
OIL RING
53
P0470053
CONNECTOR
17
P0470017
PISTON PIN
54
P0470054
REGULATOR
18
PR03M
EXT RETAINING RING 12MM
55
P0470055
CONNECTOR
19
P0470019
CONNECTING ROD
56
P0470056
PRESSURE SWITCH
20
P0470020
CRANKSHAFT
57
P0470057
STRAIN RELIEF
21
PB91M
HEX BOLT M6-1 X 18
58
PLW04M
LOCK WASHER 8MM
22
P0470022
OIL FILLER BREATHER PLUG
61
P0470061
SAFETY RELIEF
23
PB91M
HEX BOLT M6-1 X 18
62
P0470062
COMPRESSION NUT
24
P0470024
OIL SIGHT GLASS
63
P0470063
TUBE
25
P0470025
O-RING
64
P0470064
POWER CORD
26
P0470026
CRANKCASE COVER
65
P0470065
TERMINAL
27
P0470027
GASKET
66
P0470066
TERMINAL
28
P0470028
OIL SEAL
67
P0470067
GRIP HANDLE
29
P0470029
CRANKCASE
68
P0470068
CHECK VALVE
30
PN03M
HEX NUT M8-1.25
69
P0470069
FOOT
31
PW01M
FLAT WASHER 8MM
70
P0470070
AIR FILTER
32
PB118M
HEX BOLT M8-1.25 X 45
71
PB09M
HEX BOLT M8-1.25 X 20
33
P0470033
LOCK GASKET
72
P0470072
DRAIN VALVE
34
P0470034
CAPACITOR 120MFD 250 VAC
73
P0470073
TANK
35
PW07M
FLAT WASHER 3MM
74
P0470074
COMPRESSION NUT 3/8
36
PLW09M
LOCK WASHER 3MM
75
P0470075
EXHAUST PIPE
37
PS12M
PHLP HD SCR M3-.5 X 6
