Installation
E
QUIPMENT
P
ACKAGING
Table 1: Equipment Packaging
GXP-280/285 GXP-1200
GXP-2000
GXP-2010
GXP-2020
Main Case
Yes
Yes
Yes
Yes
Yes
Handset
Yes
Yes
Yes
Yes
Yes
Phone Cord
Yes
Yes
Yes
Yes
Yes
Power Adaptor
Yes
Yes
Yes
Yes
Yes
Ethernet Cable
Yes
Yes
Yes
Yes
Yes
High Phone Stand
No
Yes
No
Yes
Yes
Low Phone Stand
Yes
No
No
Yes
Yes
Wall Mount Spacers (2)
No
Yes
No
Yes
Yes
C
ONNECTING
Y
OUR
P
HONE
The connectors of the GXP1200/2010/2020 are located on the bottom of the device while they are located on
the back side of the GXP280/285/2000.
Table 2: GXP Connectors
EXT
Connects the GXP Extension unit directly to the GXP using connection cable.
Draws power from PoE if provided by network.
PC
10/100Mbps RJ-45 ports for PC (downlink) connection.
LAN
10/100Mbps RJ-45 port for LAN (uplink) connection. Supports PoE (802.3af).
Draws power from either spare line or signal line.
Power Jack
5V DC power port; UL Certified
Headset Jack
RJ22 and 2.5mm for GXP-280/285/2010/2020
RJ22 for GXP-1200
2.5mm for GXP-2000 HW Rev1.0 or later
Handset Jack
RJ11
GXP-2000
E
XTENSION
U
NIT
GXP–2000 supports two (2) extension units, providing up to 112 additional programmable extensions. Each
GXP Extension unit has 56 multi–purpose keys, dual color LEDs (red/green) and support BLF (Busy Lamp
Field) and Presence.
GXP–2000 Extension package contains:
