Section 6: Know your Laminator
This section is intended to aide the user in becoming more familiar with the 1244 WF & 1264
WF laminators. Refer back to this section if you have questions regarding references to certain
parts of the laminator in this laminator.
1.) Safety Shield 9.) Rewind Clutch Adjustment Knob
2.) Control Panel 10.) Rewind Shaft & Rewind Tube
3.) Feed Table 11.) Rear Slitter
4.) Lower Film Shaft/Unwind Shaft 12.) Power Switch
5.) Upper Film Shaft/Unwind Shaft 13.) Foot Pedal
6.) Unwind Brake 14.) Power Cord
7.) Pressure Plate 15.) Web Clutch
8.) Emergency Stop/E-Stop 16.) Roller Lift Handle/Gap Adjustment Handle
