FADER REPLACEMENT
Befor replacing the FADER you must first remove the main faceplate of
the MM-1000. Start by removing all the FADER type knobs like the
CHANNEL fader the GRAPHIC EQ and of course the CROSSFADER
itself. after you have completed that, you must remove the six screws
located on the front of the faceplate.
then gently lift the plate to uncover the the old CROSS FADER.
Then follow the next four steps to replace the actual fader.
1. UNSCREW THE FADER (B) SCREWS. DO NOT TOUCH
INSIDE SCREWS (C) CAREFULLY REMOVE OLD CROSS FADER
AND UNPLUG CABLE (D)
2. PLUG IN THE NEW CROSS
FADER INTO CABLE (D) AND
PLACE BACK INTO MIXER.
3. SCREW THE CROSS FADER
TO MIXER WITH THE FADER
PLATE SCREWS (B)
4. REPLACE THE FACE OF THE
MIXER AND SCREW THE FOUR
SCREWS BACK IN AND REPLACE THE FADER KNOBS.
NOTE: WHEN USING THE CROSS FADER LIGHTLY GLIDE THE
FADER BACK AND FORTH. PRESSING DOWN ON THE CONTROLS
CAN BEND CONTACTS AND CAUSE A LOSS OF SOUND.
MASTER FADER
The MASTER FADER adjusts the volume of the main music program.
MONO/STEREO SWITCH
The MONO/ STEREO SWITCH allows you to set the main output to mono
which is a combination of both LEFT and RIGHT inputs .
And STEREO which is a standard LEFT pan RIGHT pan stereo setup.
CHANNEL CUE BUTTONS
The CHANNEL CUE BUTTONS allow you to individually choose which
channel you wish to monitor in your headphones, you can monitor one at
a time or any combination of the three.
CUE/PGM ROTARY KNOB
The CUE/PGM ROTARY KNOB determines the mix between the chosen
CHANNEL CUE BUTTON(s) and the MAIN OUTPUT mix.
CUE VOLUME ROTARY KNOB
The CUE VOLUME ROTARY KNOB adjusts your HEADPHONE MONI-
TOR OUTPUT’S volume.
HEADPHONE MONITOR OUTPUT
The HEADPHONE MONITOR OUTPUT will accept any standard 1/4”
connector and can be used for CUE MONITORING as described above.
5 BAND GRAPHIC EQUALIZER
The 5 BAND GRAPHIC EQUALIZER adjust the tone of the MAIN OUT-
PUTS by giving you a choice 5 frequencies (BANDS) to adjust , from lows
60Hz and 400Hz to midrange 1KHz to highs 6KHz and 15KHz you can
use the adjustment sliders to higher or lower the 5 separate frequencies
till the sound of the MAIN OUTPUT’s is appropriate to your listening envi-
roment.
VU METER AND VU MODE SWITCH
The MM-1000 has a dual mode VU METER that allows you to monitor the
decible levels of the CUE and PGM or LEFT and RIGHT stereo levels of
the MASTER output. When the VU MODE SWITCH is set to CUE the VU
METER will display the CUE/PGM level or if set to MASTER the VU
METER will display the level of the MASTER output.
CONTROLS CONTINUED
13
14
15
16
17
18
19
20
“Ipod Friendly” Cable: To connect your Ipod or
other Digital Media Player, use the included Ipod
cable.
Connect the 1/8” end of the cable to the headphone
or line out jack of your player, and connect the RCA
to the line input of your mixer.
SPECIFICATIONS
INPUTS:
Phono.....................................................................................3mV,47 KOhm
Line..................................................................................150 mV, 27 KOhm
MIC......................................................................1.5 mV, 1 KOhm Balanced
OUTPUTS:
Max...................................................................................20V Peak-to-Peak
Rec.....................................................................................225 mV, 5 KOhm
GENERAL:
Frequency Response.................................................20Hz - 20KHz +/- 2dB
Distortion..........................................................................................< 0.02%
S/N Ratio...........................................................................Better than 85 dB
Headphone impedance..................................................................16 Ohm
Power Source (external)......................................................AC 15V, 500mA
Unit Demensions.....................................................................19” x 3.3” x 7”
..........................................................................(482.6 x 83.82 x 177.8 mm)
Weight................................................................................6.35 lbs (2.88 kg)
SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTIFICATION FOR IMPROVEMENT
MM-1000
