Generac Portable Products 7000EXL Extended Life Generator
20
PARTS LIST – ALTERNATOR & FRAME
Item
Part #
Qty Description
1
A187024
1
CRADLE
2
J189176
1
SHIELD, Heat
3
92982
1
DECAL, Danger
4
92665
1
INSULATION, #2-1/4" Thick
5
B1998
1
TANK, Fuel (Incls Item 12 & 13)
6
B4363
1
CAP, with Gauge, Fuel
7
85000
1
CLIP, Insulation
8
93826
1
DECAL, Start Instructions
9
78831B
4
HHMS, M6-1.0 x 60, SEMS
10
83465
4
GROMMET,Tank
11
77395
8
NUT, Flange Lock - M6
12
80270
1
VALVE,Tank
13
78299
1
BUSHING,Tank
14
B2153
9
SCREW, 12-14 x 7/8, Self Driller
15
43116
4
HHCS, M6 - 1.0 x 12
16
51731
2
HHCS, M8 - 1.25 x 50
17
B4135
2
PIN, with Lanyard
18
187104
4
WASHER, Nylon
19
49820
2
NUT, M8 Nylok
20
83083
1
SCREEN, Spark Arrester
21
86307
4
HHMS, 5/16-24 x 3/4"
22
92247
1
HOUSING, Engine Adapter
23
A92531
1
SUPPORT, Engine
24
189160
12
NUT, 5/16-18 Flange Serrated
25
22129
2
WASHER, Lock - M8
26
82857
4
MOUNT,Vibration
27
22531
2
HHCS, 5/16-18 x 1-3/4"
28
92609
2
MOUNT,Vibration
29
22142
2
SCREW, 5/16 - 18 x 3/4"
30
A7433
1
MUFFLER
31
A92731
1
SUPPORT, Engine & Muffler
32
90239
1
GASKET, Muffler
33
B1342G
1
ASSEMBLY, Rotor (Incls Item 34)
34
65791
1
BEARING
35
96796
1
WASHER, Special Flat - M8
36
47481
1
HHCS, 5/16-24 x 10-5/8
37
B1897G
1
ASSEMBLY, Stator
38
20566
1
DECAL, 1-800
39
40976
2
SCREW, M8 - 1.25 x 20
40
92532
1
BRACKET, Muffler
41
66476
2
CAPSCREW, M6 - 1.0 x 12mm
42
186747
1
DECAL, Control Panel
43
92630
1
ASSEMBLY, Control Box
44
J96068
1
SHIELD, Heat
45
14353621
1
WIRE, Ground
46
26850
2
LW, EXT, Shakeproof M6
47
BB3061
2
BOTTLE, Oil
48
81917
1
PIN, Roll 4mm x 10
49
B4986
1
DECAL, Ground
50
186798
2
DECAL, Heat Shield
51
56893
5
CRIMPTITE, 10-24 x 1/2"
52
84132
1
ASSEMBLY, Power Regulator
Item
Part #
Qty Description
53
67022
1
GROMMET, Rubber
54
66825C
1
CARRIER, Rear Bearing
55
86494
1
SCREW, M6-1.0 x 16 Wing
56
23762
3
WASHER, Shakeproof #10
57
66386
1
ASSEMBLY, Brush Holder
58
66849
2
TAPTITE, M5-0.8 x 16
59
B4871
1
COVER, Bearing Carrier
60
74908
4
TAPTITE, M5-0.8 x 10
61
B4605
2
GRIP
62
66849C
1
TAPTITE, M5-0.8 x 30
63
65795
2
RECTIFIER, Battery Charge
64
66449L
4
BOLT, Stator M6-1 x 190mm
65
22145
4
WASHER, Flat 5/16 - M8
66
22097
5
LOCKWASHER, 1/4" - M6
67
186744
1
MANUAL, Operators
68
BB5586
2
HANDLE
69
52858
4
NUT, Lock M8
70
B186927
1
LEG, Support
71
27007
2
MOUNT,Vibration
72
42909
2
CAPSCREW, M8 - 1.25 x 30
73
93693G
1
AXLE
74
B4966
2
WHEEL
75
22247
2
WASHER,Wheel
76
87005A
2
PIN, Retaining
77
189302B
1
WIRE ASM, #16
78
77282
1
SWITCH, Starter
79
188987
1
BRACKET, Switch
80
188989
1
ASM, Jack, DC
81
22287
2
HHCS, 1/4 - 20 x 3/4"
82
22097
4
LOCKWASHER, 1/4 - M6
83
22127
5
NUT, 1/4 - 20
84
J186704
1
TRAY, Battery
85
B4489
1
BATTERY, 12V 18 AH
86
189302C
1
WIRE ASM, #13
87
185939H
1
WIRE ASM, #55
88
73054
1
DECAL, Fuel Shut-Off
89
77816
2
DECAL, Hot Muffler
90
39253
2
HHCS, M8 - 1.25 x 20
91
A8927
1
MANUAL, Engine
92
52618
2
HHCS, M5 - 0.8 x 12
93
23897
2
WASHER, M5 Flat
94
52856
2
NUT, M5 Flange Hex
95
50190
2
WASHER, Flat 10 GA 0.34 x 1
96
96113
1
WIRE ASM, #13
97
58359
1
LUG, 5/16 #22/18 I-S
98
189198
1
DECAL, Instruction, ES
99
B4177
1
CHARGE, Battery Float
100
189208
3
FUEL STABILIZER, 1oz Tube
101
65787
1
CABLE, Battery Charge
102
37806
1
PLUG, 120V/30 Amp
103
188971
1
EXTENDA PANEL
900
NSP
1
ENGINE
