SWITCH (25) to the center position to split the signals from each
channel so that CHANNEL 1 will be heard in one earphone and
CHANNEL 2 will be heard in the other earphone. Use the CUE LEVEL
(5) control to adjust the headphone volume without effecting the
overall mix.
8. DISPLAY: The DISPLAY (20) indicates the MASTER output.
Specifications
INPUTS:
DJ Mic....................................................................................1.5 mV 600 Ohm
Phono.......................................................................................3 mV 47 kOhm
Line.....................................................................................150 mV 27Kohm
OUTPUTS:
Amp..................................................................................0 dB 1V 400 Ohm
Max..............................20V Peak to Peak
GENERAL:
Gain (Channels 1 - 2)..............................................................0 to -20 dB
Frequency Response................................................20Hz - 20 kHz +/- 2 dB
Distortion............................................................................................0.02%
S/N Ratio...........................................................................better than 80 dB
Talkover Attenuation............................................................................-16 dB
Headphone Impedance.......................................................................16 Ohm
Power Source.................................................................115V/15V AC 7.5 W
230V/15V AC 7.5 W
Dimensions........................................6.5” x 14” x 3” (165 x 355 x 85 mm)
Weight....................................................................................4.76 lbs (2 kg)
