QT022
INTERCONNECTIONS
22 240 1 Ø 125 #2 to 1/0
22 208 3 Ø 100 #4 to 1/0
INSTALLATION LAYOUT
INSIDE LOCATED High voltage. may result in personal Contact with terminals injury or death.
HI COOLANT TEMPERATURE
LOW OIL PRESSURE
LOW FUEL PRESSURE LOW BATTERY SYSTEM READY
FUSES
AUTO
MANUAL
OFF OFF ON TIME SET EXERCISE
LOW COOLANT LEVEL OVER SPEED OVER CRANK
DANGER
28.98
FRONT VIEW
62.2
46.02
DOOR TYP
33.5
SEE INSTALL DWG 0G9370 FOR DETAILS
HOURS 1/10
QUARTZ
Installation Drawing Ref. No. 0G0325
Generac Power Systems, Inc. • P.O. Box 8, Waukesha, WI 53187 • generac.com
©2008 Generac Power Systems, Inc. All rights reserved. All specifications are subject to change without notice. Bulletin 0179200SBY/Printed in U.S.A. 09.08
WEIGHT: 843 lbs.
