Mode 10 11 12 13 14 15 16 18
H Resolution 1024 1024 1024 1024 1280 1280 1280 720
V Resolution 768 768 768 768 1024 1024 1024 400
Refresh Rate 60 70 75 85 60 75 85 70 Hz
Pixel 65 75 78.75 94.5 108 135 157.5 28.320 MHz
Horizontal visible 1024 1024 1024 1024 1280 1280 1280 720 Dots
Horizontal total 1344 1328 1312 1376 1688 1688 1728 900 Dots
Horizontal front porch 24 24 16 48 48 16 64 18 Dots
Horizontal sync 136 136 96 96 112 144 160 108 Dots
Horizontal back porch 160 144 176 208 248 248 224 54 Dots
Horiz blanking time 320 304 288 352 408 408 448 180 Dots
Vertical visible 768 768 768 768 1024 1024 1024 400 Lines
Vertical total 806 806 800 808 1066 1066 1072 449 Lines
Vertical front porch 3 3 1 1 1 1 1 12 Lines
Vertical sync 6 6 3 3 3 3 3 2 Lines
Vertical back porch 29 29 28 36 38 38 44 35 Lines
Vertical blanking time 38 38 32 40 42 42 48 49 Lines
Horizontal frequency 48.4 56.5 60 68.7 63.98 79.98 91.15 31.46 KHz
Vertical frequency 60.01 70.07 75.03 84.99 60.02 75.03 85.02 70.08 Hz
Vertical sync polarity - - + + + + + + TTL
Horiz sync polarity - - + + + + + - TTL
Dot rate 65 75 78.75 94.5 108 135 157.5 28.32 MHz
