1

098675

1

ASSY ROTOR 20KW

2

0A5336A

1

HOUSING BLOWER

3

0A1659

1

SCREEN AIR OUTLET

4

020746

4

SCREW PPHM M5-0.8 X 8 ZINC

5

049226

4

WASHER LOCK M5

6

051713

4

WASHER FLAT M5

7

022129

4

WASHER LOCK M8-5/16

8

0F8218

1

ASSY STATOR 20KW 1PH A

0F8220

1

ASSY STATOR 20KW 3PH GJK

9

0A5382

1

BEARING CARRIER REAR

10

075591

1

ASSY HOLDER BRUSH

11

075476

4

SCREW PPHM M4-0.7 X 16

12

0A5601A

1

COVER REAR BEARING

13

075554B

4

BOLT STATOR X 16" LG

14

0A9375

4

SCREW RHM #10-24 X 2

15

022152

4

WASHER LOCK #10

16

097146

1

FAN & RING GEAR ASSEM.

17

042558

1

KEY SQ 3/8 X 1 STEEL

18

0A5061

1

SPACER-FLEX PLATE

19

0A4989

1

PLATE FLEX

20

053607

1

SCREW HHC M12-1.75 X 35 G8.8

21

051769

6

WASHER LOCK M12

22

049541

4

SCREW HHC M10-1.5 X 35 G8.8

23

046526

4

WASHER LOCK M10

24

045772

4

NUT HEX M10-1.5 G8 YEL CHR

26 *

087599

2

PLUG PLASTIC 3/8 NPT

27

077043E

1

FLEX CONDUIT 1" BLACK (NOT SHOWN)

28

022131

4

WASHER FLAT 3/8-M10 ZINC

29

072578

1

SPACER ROTOR SHAFT

30

0A7043

5

SCREW HHC M12-1.25 X 25 G8.8

31

049808

5

WASHER FLAT M12

32

058589

1

DECAL WARN ENG START

33

023365

4

WASHER SHAKEPROOF INT #8

35

0A8830

4

WASHER FLAT .34 ID X .75 OD

36

072080

1

DECAL DANGER STANBY UNITS
