Page 4, Figure 1 - features - typical - standard models, Figure 2 - overall dimensions – Guardian Technologies WRT-10-A User Manual
Page 4
Guardian Telecom Inc.
Installation and Operation
Model WRT-A
Page 4
MAGNETIC REED HOOK SWITCH
3X4 KEYPAD
(WRT-10-WATERPROOF, WRT-30 &
WRT-40 - METAL)
VELCRO DOOR LATCH
ID & APPROVALS
HEAVY DUTY HANDSET
CORD
WIRING ACCESS PLATE
16 GA STEEL, SATIN COAT
PRIMED AND POWDER COATED
Figure 1 - Features - Typical - Standard Models
3
.8
"
[9
7
m
m
]
2
.9
"
[7
4
m
m
]
3
.9
"
[9
9
m
m
]
9.7" [246mm]
1
4
.0
"
[3
5
6
m
m
]
1
2
.0
"
[3
0
5
m
m
]
1
1
.8
"
[3
0
0
m
m
]
8.8" [224mm]
1
3
.0
"
[3
3
0
m
m
]
3.0" [75mm]
Ш0.3" [Ш7mm]
Figure 2 - Overall Dimensions
