Generac Power Systems 1.6L 18 kW - Manual (Page 39)

1 0F3408C 1 BATTERY TRAY, C1 & C2
2 0F3411 1 STRAP BATTERY RETAINMENT
3 025507 1 WASHER SHAKEPROOF EXT 7/16 STL
4 059980 1 SCREW HHC M10-1.5 X 25 G10.9
5 046526 1 WASHER LOCK M10
6 077483 REF BATTERY 12VDC 75-AH 26
7 050331A REF BATTERY POST COVER RED +
8 050331 REF BATTERY POST COVER BLK -
9 038805J 1 CABLE BATTERY BLACK #1 X 30.00
10 038804M 1 CABLE BATTERY RED #1 X 21.00
11 045771 REF NUT HEX M8-1.25 G8 YEL CHR
12 022131 1 WASHER FLAT 3/8-M10 ZINC
13 027482 1 WASHER SHAKEPROOF EXT 5/16 STL
14 0F3976 1 BOOT CONTACTOR CABLES
15 0C2454 4 SCREW THF M6-1 X 16 N WA Z/JS
16 022145 REF WASHER FLAT 5/16-M8 ZINC
NOTE: WHEN INSTALLING BATTERY, TUCK BATTERY’S LIFTING STRAP ALONG
THE LEFT SIDE OF BATTERY ( SIDE OPPOSITE RADIATOR) BEFORE
CONNECTING THE BATTERY CABLES.
